2.2 Front Panel LEDs

LED
Color
Green
P1
Green
P2
Green
Fault
Fiber
Green
LNK/ACT
TP
Green
LNK/ACT
Green
TP 1000
Amber
PoE-in-Use
Lit: To indicate power 1 has power.
Lit: To indicate power 2 has power.
Lit: To indicate either power 1 or power 2 has no power.
Lit: To indicate the link through ber port is successfully established.
Blinks: To indicate the ber port is actively sending or receiving data.
O : To indicate that the ber port is linked down.
Lit: To indicate the link through TP port is successfully established.
Blinks: To indicate the TP port is actively sending or receiving data.
O : To indicate that the TP port is linked down.
Lit: To indicate that the TP port is operating at 1000Mbps.
O : To indicate that the TP port is operating at 10/100Mbps.
Lit: To indicate that the port is providing PoE Power to remote
powered device.
O : To indicate that the port is not providing PoE Power to remote
powered device.
Description
- 5 -
