MA Scancommander Manuel d'Utilisation
Manufacturer STARLITE
Scan type: STARLITE MK2G H.Res
Short name: MK2G
Movement: Head - Brightness Master on Shutter
DMX channel order
1: Iris 2: Color
4: Shutter 5: Pan coarse
7: Tilt coarse 8: Tilt fine
Test: No, Presets available
————————————————————————————
Manufacturer STUDIO DUE
Scan type: VARYBEAM
Short name: VARY B
Movement: Head - Brightness Master on Shutter
DMX channel order
1: Pan 2: Tilt
4: Gobo 1 5: Shutter
7: Gobo 2
Test: No
————————————————————————————
Scan type: STRATOS High Res
Short name: STRA H
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Iris 2: Colour 1
4: Shutter 5: Pan coarse
7: Tilt coarse 8: Tilt fine
10: Speed 1 11: Focus
13: Gobo 2 14: Rotation 1
Test: No, Presets available
————————————————————————————
Scan type: STRATOS HR
Short name: STRA H
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Iris 2: Colour 1
4: Shutter 5: Pan coarse
7: Tilt coarse 8: Tilt fine
10: Speed 1 11: Focus
13: Gobo 2 14: Rotation 1
Test: No, Presets available
————————————————————————————
Scan type: STRATOS RGB High RG
Short name: STRA R
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Frost 2: Colour
4: Shutter 5: Pan coarse
7: Tilt coarse 8: Tilt fine
10: (M-)Speed 1 11: Magenta
13: Yellow 14: (D-)Speed 2
Test: No, No Presets available
————————————————————————————
Scan type: STRATOS RGB High RI
Short name: STRA R Reset=Gobo1
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Frost 2: Colour
4: Shutter 5: Pan coarse
7: Tilt coarse 8: Tilt fine
10: (M-)Speed 1 11: Magenta
13: Yellow 14: (D-)Speed 2
Test: No, No Presets available
Protocol: DMX 512
3: Gobo
6: Pan fine
9: Focus
Protocol: DMX 512
3: Color 1
6: Speed 1
Protocol: DMX 512
3: Gobo 1
6: Pan fine
9: Dimmer
12: Colour 2
Protocol: DMX 512
3: Gobo 1
6: Pan fine
9: Dimmer
12: Colour 2
15: Reset=Special
Protocol: DMX 512
3: Gobo
6: Pan fine
9: Dimmer
12: Cyan
15: Reset=ISpecial
Protocol: DMX 512
3: Iris
6: Pan fine
9: Dimmer
12: Cyan
15: Reset=Special
MA Lighting Technology GmbH Höhenweg 6 D-97249 Eisingen Tel.:(49) 9306 2459
————————————————————————————
Scan type: STRATOS Low Res
Short name: STRA L
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Iris 2: Colour 1
4: Shutter 5: Pan
7: Dimmer 8: Speed 1
10: Colour 2 11: Gobo 2
Test: 1/94, Presets available
————————————————————————————
Scan type: MINIBEAM
Short name: MINI B
Movement: Head - Brightness Master on Shutter
DMX channel order
1: Speed 1 2: Colour 1
4: Shutter 5: Pan
Test: 1/94, Presets available
————————————————————————————
Scan type: CARIOCA
Short name: CARIOC
Movement: Mirror 1 way only
DMX channel order
1: Iris 2: Pan
4: Color 1 5: Tilt=not used
Test: 1/94, Presets available
————————————————————————————
Scan type: STRATOS HR Dim neg.
Short name: STRA H
Movement: Head - Brightness Master on Dimmer invers
DMX channel order
1: Iris 2: Colour 1
4: Shutter 5: Pan coarse
7: Tilt coarse 8: Tilt fine
10: Speed 1 11: Focus
13: Gobo 2 14: Rotation 1
Test: No, Presets available
————————————————————————————
Scan type: STRATOS LR Dim neg.
Short name: STRA L
Movement: Head - Brightness Master on Dimmer invers
DMX channel order
1: Iris 2: Colour 1
4: Shutter 5: Pan
7: Dimmer 8: Speed 1
10: Colour 2 11: Gobo 2
Test: 1/94, Presets available
————————————————————————————
Manufacturer SUMMA
Scan type: SUMMA HTI
Short name: SUMMA
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Color 1 2: Color 2
4: Tilt 5: Speed 1
7: Zoom 8: Focus
Test: No
————————————————————————————
Protocol: DMX 512
3: Gobo 1
6: Tilt
9: Focus
12: Rotation 1
Protocol: DMX 512
3: Gobo 1
6: Tilt
Protocol: DMX 512
- Brightness Master on Shutter
3: Shutter
Protocol: DMX 512
3: Gobo 1
6: Pan fine
9: Dimmer
12: Colour 2
Protocol: DMX 512
3: Gobo 1
6: Tilt
9: Focus
12: Rotation 1
Protocol: DMX 512
3: Pan
6: Gobo 1
9: Dimmer
