3.2 Beam angle

The Projector is best to be placed 5 meters from wall, and from this distance the light effect will cover an area of
3.7 m x 3.7 m.

4. WT-LGP

Logo Projector is a powerful tool creating a long lasting visual effect. It comes with 7 D size gobos and an inter-
changeable slot for custom made gobos. With speed and direction adjustable function, the Logo projector is
perfect for discos, restaurants, department stores, etc.
• Adjustable gobo rotation direction and speed.
• With an optional CA-5 easy controller for the on/off control.
• Focus adjustable and fan cooled.
Specification:
• Voltage: AC 120V~60Hz 230V/240V/250V~50Hz/60Hz
• Fuse: 20mm glass 250V T6.3A / 20mm glass 250V T5A
• Bulb: EHJ 24V 250W
• Dimension: 306 x 263 x 140 mm
• Weight: 8.2 kgs

4.1 Change lamp

• Always switch off the mains supply and never handle the lamp or luminaire when it is
hot.
• Do not touch the bulb with bare hands. If this does happen, clean the lamp with
denatured alcohol and wipe with a lint free cloth before installing.

4.2 Inserting/Exchanging rotating gobos

Gobo list:
Pull the socket off the lamp.
Do not pull the wires.
