Weco Discovery 221AC/DC Evo Guide D'utilisation page 68

Cod. 006.0001.2000
19/07/2018 V.2.0
FRANÇAIS
N° CODE DESCRIPTION
1 014.0002.0002 KNOB
FRONT PANEL LABEL (221AC/DC
2 013.0012.1701
EVO)
COMPLETE LOGIC FRONT PA-
3 001.5171.0000
NEL (221AC/DC EVO)
REAR PLASTIC PANEL
4 010.0006.0034
5 010.0006.0033 FRONT PLASTIC PANEL
6 042.0003.0034 POWER TRANSFORMER
7 044.0004.0025 OUTPUT INDUCTANCE
8 010.0002.0004 HF TRANSFORMER
TRANSFORMER SUPPORT
9 011.0002.0012
10 005.0001.0008 BELT
11 050.0002.0070 POWER BOARD
12 016.0010.0001 BOARD SUPPORT GUIDE
13 050.0003.0071 INVERSION BOARD
HF BOARD
14 050.0003.0027
15 050.0001.0074 LINE FILTER BOARD
UPPER COVER
16 011.0000.0161
17 011.0003.0057 BOOST INDUCTANCE SUPPORT
18 044.0004.0017 BOOST INDUCTANCE
19 011.0008.0020 UPPER PLATE
20 040.0001.0011 BI-POLE SWITCH
SOLENOID VALVE
21 017.0001.5542
22 011.0002.0018 SOLENOID VALVE PLATE
23 013.0012.0500 REAR PANEL
24 022.0002.0081 COOLING UNIT SUPPLY CABLE
25 021.0013.0007 ILME CONNECTOR CAP
REMOTE CONTROL WIRING
26 022.0002.0079
27 045.0000.0007 CABLE CLAMP
28 011.0008.0010 EXTERNAL FAN SUPPORT
29 003.0002.0004 FAN
30 011.0008.0011 INTERNAL FAN SUPPORT
INVERSION MODULE BOARD
31 050.0001.0099
32 040.0003.1003 TERMAL SWITCH L=290mm 75°C
INVERSION MODULE (+) BRA-
33 045.0006.0059
CKET
INVERSION MODULE (-) BRA-
34 045.0006.0060
CKET
35 050.0002.0065 SNUBBER BOARD
DIODES-TRANSFORMER
36 045.0006.0057
PER BRACKET
37 045.0006.0058 (+/-) DIODES COPPER BRACKET
DIODE
38 032.0002.2006
39 040.0003.1002 TERMAL SWITCH L=200mm 75°C
40 045.0002.0008 SUPPLY CABLE
41 011.0008.0029 LATERAL PLATE
42 015.0001.0006 HEAT SINK
68
WELD THE WORLD
N° CODE
43 041.0004.0301
44 050.0001.0042
45 011.0002.0036
46 021.0001.0259
47 050.0001.0075
48 016.0009.0003
49 011.0008.0001
COP-
Discovery 221AC/DC Evo
Discovery 300AC/DC Evo
DESCRIPTION
HALL SENSOR
AMPHENOL CONN. BOARD
SOLENOID VALVE BLOCK
COMPLETE FIXED SOCKETS
400A
OUTPUT FILTER BOARD
RUBBER FOOT
LOWER COVER
