Blooma Tabor Manuel D'utilisation page 35

[01] x 1
[05] x 1
[09] x 1
[13] x 1
[21] x 4 (Ø5)
[23] x 2
634016-BBQ-Blooma-IM-FR-PL-A5-V05.indd 35
[02] x 2
[06] x 2
[10] x 2
[14] x 1
1 : 1
[22] x 4 (Ø6)
[03] x 1
[07] x 1
[11] x 2
[19] x 4 (M5) [20] x 2 (M8)
[15] x 4 (M6 x 40 mm)
[16] x 2 (M6 x 35 mm)
[17] x 14 (M6 x 10 mm)
[18] x 4 (M5 x 10 mm)
[04] x 1
[08] x 1
[12] x 1
