GB
• Never turn the machine on when peo-
ple and particularly children or animals
are nearby.
• People with motor disorders are not to
operate the machine without supervi-
sion.
• Do not use the machine with bare feet
or when wearing open sandals. Only
run the machine at walking pace.
• When working, ensure a firm foothold,
particularly on slopes. Always work
across the slope, never up or down-
wards. Take particular care when
changing the direction of travel on the
slope. Do not work on excessively
steep slopes.
• When switching the machine on, avoid
feet or hands being trapped between
the moving blades and the fixed parts
of the machine.
• Never carry the machine by the blade
cylinder.
Caution! To avoid damaging the
machine and potential injury as a
consequence:
• Check the terrain on which the ma-
chine is used and remove stones,
sticks, wires or other foreign bodies
that may be picked up and flung out-
wards.
• Ensure that the machine is in a safe
operating condition. Replace worn or
damaged parts.
• Protect the machine from the effects of
weathering (damp, frost).

Assembling the handle

1. Place the upper handle (7) on
the two centre pieces (8) and fix
it with two bolts (10) and wing
nuts (11).
12
2. Put the two lower handles (9)
together and fix them with two
bolts (10) and wing nuts (11).
3. Fasten the centre pieces (8) to
the lower handle parts (9) with
two bolts (10) and wing nuts
(11).
4. Press the bow-type handle (1)
together a little and put the bow-
type handle (1) onto the bracket
on the lawn mower housing (12).

Adjusting the cut height

The cut height is infinitely adjustable
(14 – 47 mm) by changing the position of
the rollers:
Loosen the wing screws on both
sides of the equipment and set
the desired cut height. Ensure that
both axles are set to the same
height.
Set the cut height no lower than to
where the blade cylinder does not
touch the ground even where it is
uneven.
Assembling/emptying the
grass bag
1. Hang the grass bag in the bra-
ckets provided for this.
2. Fasten the grass collection bag
(6) to the crossbar of the lower
handles (9) with the strap (16).
3. To remove/empty the grass col-
lection bag (6), loosen the strap
(16) and unhook the grass col-
lection bag.
