SIMPLIFIED EU DECLARATION OF CONFORMITY
SIMPLIFIED EU DECLARATION OF CONFORMITY
The manufacturer Glomex declares that the radio equipment type weBBoat 4G Plus is
The manufacturer Glomex declares that the radio equipment type weBBoat 4G Plus is
in compliance with European Directive 2014/53/EU. The full text of the EU Declaration
The manufacturer Glomex declares that the radio equipment type weBBoat 4G Plus is
in compliance with European Directive 2014/53/EU. The full text of the EU Declaration
is available at the following internet address:
in compliance with European Directive 2014/53/EU. The full text of the EU Declaration
is available at the following internet address:
http://www.glomex.it/leisure/eng/certifications.php
is available at the following internet address: http://www.glomex.it/leisure/eng/certifications.php
http://www.glomex.it/leisure/eng/certifications.php
TECHNICAL SPECIFICATIONS
Antenna dimensions (diam.x H): 250 x 300 mm / 10x12"
Antenna weight: 1,2 kg / 2,65 lb
Automatic switch from Wi-FI registered networks to 4G.
DUAL SIM Management
Roaming Management
4G backup WAN function
LTE 4G up to 100 Mbps in download and 50 Mbps in upload
DC-HSPA+ up to 42 Mbps in download and 5.76 Mbps in upload
3 Ethernet ports
4 Diversity high performance antennas
SMS reboot function
Android and iOS App for an easy control
Easy installation requires only power supply connection 12/24V
UV waterproof resistant Dome
Automatic Firmware upgrade
General Feautures
LTE FDD bands: B1/B2/B3/B5/B7/B8/B20
DC- HSPA+/HASPA+/HSPA/UMTS: 850/900/1900/2100 MHz
GSM/GPRS/EDGE: 800/850/1800/1900 MHz
Power Class 3 (23 dBm) for LTE FDD
Power Class 3 (24 dBm) for UMTS
Power Class E2 (26 dBm) for EDGE 1800/1900 MHz
Power Class E2 (27 dBm) for EDGE 850/900 MHz
Power Class 1 (30 dBm) for GSM/GPRS 1900/1800 MHz
Power Class 4 (33 dBm) for GSM/GPRS 900/850 MHz
Data Rates
Mode LTE: DL 100 Mbps - 50 Mbps UL
DC-HSPA+: DL 43,2 Mbps - 5,76 Mbps UL
WCDMA PS: DL 384 Kbps - 384 Kbps UL
EDGE: DL 236,8 Kbps - 236,8 Kbps UL
GPRS: DL 85,6 Kbps - 85,6 Kbps UL
Complies with IEEE 802.11b/g/n wireless standard
Complies with IEEE 802.3 and IEEE 802.3u Ethernet standards
LABEL
1
weBBoat 4G Plus
GL00159
