The work area can be illuminated thanks to an LED.
For an improved guidance, a laser can be switched
on in addition, which indicates the current cutting
path.
Furthermore the device is equipped with a fan
function for a cutting line without sawdust and with
an integrated connection for effective external
vacuum cleaning.
Device depiction
1
19
18
17
16
15
14
13
12
EN
11
No. Designation
2
1
2
3
3
4
4
5
5
6
6
7
8
9
10 Adapter for dust extraction
11 Anti-splinter guard
12 Guide roller
13 Quick-release chuck
14 Base plate lock
15 Locking screws for rip fence
16 Protective cover
17 Laser, LED work light
18 Button for laser and LED work light
19 Lock-on switch continuous operation
7
850W pendulum action jigsaw PJSS 10-230V
Stroke rate setting wheel
On/off switch
Dust extraction connection
Splinter blow-off/suction selector switch
Pendulum action selector switch
Base plate with removable sliding block
Protective pin
Rip fence
Saw blade set
8
9
10
