1.
General
The module design is based on RF transceiver with integrated MCU core, CC2541. It implements a proprietary
communications protocol streamlined to lower cost and power consumption. The antenna used is
antenna. The module will be FCC and TELEC certified for fast and simple integration into end applications.
module may be integrated into a wireless application that operates in 2.4G ISM frequency band.
1.1
Product Features
Model
Dimension (in mm)
RF Standard
Modulation
Frequency Band
Channel list
Radio Range
Transmit Power (EIRP)
Receiver Sensitivity
General purpose I/O
1.2
Operating Specification
Voltage
Current
Operating Temperature
Storage Temperature
Humidity
:
TRK-RF-07 (RF_CC2541 Module BL02)
:
70.2(L) X 24.4(W) X 3.0(H)
:
FCC, NCC, IC
TELEC
:
GFSK
2.402 GHz – 2.480 GHz
:
:
79 Channels at 1MHz step
2402MHz +(n-1)MHz where n = 1 to 79
:
Up to 100m, L.O.S
:
10.37dBm (max)
:
-90dBm (typical), PER = 1%
:
4
:
DC 3.0V
:
150mA TX mode,
:
-20 °C to 40 °C
:
-40 to +85° C
:
95% max non condensing
7
TRK-RF-07 User Manual
a PCB
This
