1. General
The module design is based on RF transceiver with an integrated MCU core, A8131ZM0. It implements a
proprietary communications protocol streamlined to lower cost and power consumption. The antenna used is
SMA antenna. The module will be FCC certified for fast and simple integration into end applications.
module may be integrated into a wireless application that operates in 2.4G ISM frequency band.
1.1 Product Features
Model
Dimension (in mm)
RF Standard
Modulation
Frequency Band
Channel list
Radio Range
Transmit Power (EIRP)
Receiver Sensitivity
General purpose I/O
1.2 Operating Specification
Voltage
Current
Operating Temperature
Storage Temperature
Humidity
: TRK-RF-08 (2.4G RF MODULE_BL08)
: 70.2(L) X 24.4(W) X 3.0(H)
: FCC, NCC, IC
: GFSK
2.402 GHz – 2.478 GHz
:
: 77 Channels at 1MHz step
2402MHz + (n-1) MHz where n = 1 to 77
: Up to 100m, L.O.S
: 9.74dBm (max)
: -90dBm (typical), PER = 1%
: 4
: DC 5.0V
: 130mA TX mode,
: -20 °C to 40 °C
:
-40 to +85° C
: 95% max non condensing
