Raider PRO RDP-HPC14 Mode D'emploi page 97

No. English Name
1 Rear housing
2 wheel
3 wheel protector
4 axle
5 washer D12
6 Shaft elasticity washer D12 2
7 wheel cover
8 rating label
9 power cord hook
10 waring label
11 powe cord with plug
12 Pipette
13 Pipe
14 soap bottle
15 cap for soap bottle
16 screw ST4.8*20
17 accessories holder
20 Locking spring
21 Pull rod lock
22 Pull rod button
23 Pull rod
24 conduit for right pull rod
25 conduit for left pull rod
26 screw M6*42
27 Screw M6
28 handle cover
29 handle
30 Rubber sleeve
31 nozzle
32 hose reel handle cover
33 hose reel handle
34 right binder plate
35 right flange
36 left flange
37 left binder plate
38 Three way valve
39 U pin
40 high pressure hose
41 O ring 7.5X2/80HS/ROHS
42 O ring 6.3X1.8/80HS/ROHS 2
SPARE PARTS
Qty No. English Name
1
2
2
1
2
2
1
1
1
1
1
1
1
1
44 58 Shaft elasticity washer ￠ 4 1
1
1
1
1
2
1
1
2
2
1
1
4
4
1
1
1
1
1
1
1
2
1
2
43 Cleaning pin
44 Three way valve
45 split washer
46 Screw M6*8
47 clip for hose
48 gun and lance
49 gun holder
50 M128
51 Main switch
52 M128 switch cover
53 screw ST3.5*16C
54 button pole
55 O ring 8X2_70HS
56 inner high pressure hose
57 washer ￠ 4
59 screw M4X8
60 Motor and pump kit
61 M128 pressplate
62 frong housing deck
63 Switch button
64 switch cover
65 switch for detergent
66 gun stock
67 water outlet cover
68 front housing
69 switch cover for detergent
70 switch for detergent
71 O ring 26.5X1.8/80HS/ROHS 1
72 pin for valve
73 O ring 5.5X2/70HS/ROHS
74 spring for valve
75 screw ST3.0*12C
76 inner pipe
77 detergent valve
78 screw M6*20
79 Pump base
80 Damping ring
81
82 Capacitor
83 Capacitor box
84 Capacitor sheath
97
Qty
1
1
1
2
1
1
1
1
1
1
11
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
4
1
2
1
1
1
1
