SPECIFICATIONS
Reference 607F Reference 697MF
6-1/2" (160mm) high performance 6" x 9" high performance
Type
coaxial car speaker three-way car speaker
60W 100W
Continuous power handling
Peak power handling 180W 300W
Frequency response 53Hz-21kHz 46Hz - 30kHz
3.0ohms 3.0ohms
Nominal impedance
Sensitivity (2.83V/1m) 93dB 94dB
External diameter 6-1/4" (158mm) 9-5/16" X 6-7/16"
(236.5mm X 163mm)
5" (127mm) 8-1/2" X 5-3/4"
Mounting cutout diameter
(214.6mm X 144.6mm)
Total depth 2-3/4" (69.7mm) 3-3/4" (93.8mm)
2-1/16" (51.5mm) 3-1/8" (77.8mm)
Mounting depth
SPÉCIFICATIONS
Reference 607F Reference 697MF
Haut-parleur automobile coaxial hautes Haut-parleur automobile trois voies hautes
Type
performances 160 mm (6-1/2") performances 152 mm x 229 mm (6" x 9")
60W 100W
Puissance admissible continue
180W 300W
Puissance admissible crête
Réponse en fréquence 53Hz-21kHz 46Hz - 30kHz
3.0ohms 3.0ohms
Impédance nominale
93dB 94dB
Sensibilité (2.83V/1m)
Diamètre externe 6-1/4" (158mm) 9-5/16" X 6-7/16"
(236.5mm X 163mm)
Diamètre de découpe 5" (127mm) 8-1/2" X 5-3/4"
(214.6mm X 144.6mm)
de montage
2-3/4" (69.7mm)
Profondeur totale 3-3/4" (93.8mm)
2-1/16" (51.5mm) 3-1/8" (77.8mm)
Profondeur de montage
ESPECIFICACIONES
Reference 607F
Reference 697MF
Altavoz para automóvil coaxial de alto Altavoz para automóvil de tres vías
Tipo
rendimiento de 9-1/2" (160 mm)
de alto rendimiento de 6" x 9"
60W
Gestión de potencia máxima continua 100W
180W
Gestión de potencia pico 300W
53Hz-21kHz
Intervalo de frecuencias 46Hz - 30kHz
3.0ohms
Impedancia nominal 3.0ohms
93dB
Sensibilidad (2.83V/1m) 94dB
6-1/4" (158mm) 9-5/16" X 6-7/16"
Diámetro externo
(236.5mm X 163mm)
5" (127mm) 8-1/2" X 5-3/4"
Diámetro de corte
para montaje (214.6mm X 144.6mm)
2-3/4" (69.7mm) 3-3/4" (93.8mm)
Profundidad total
2-1/16" (51.5mm)
Profundidad de montaje 3-1/8" (77.8mm)
Harman International Industries, Incorporated
8500 Balboa Blvd, Northridge, CA 91329, UNITED STATES.
www.infinityspeakers.com
8 6/25/2023 2:00:13 PM
Reference 307F Reference 407F Reference 507F
3-1/2" (87mm) high performance 4" (100mm) high performance 5-1/4" (130mm) high performance
coaxial car speaker
coaxial car speaker coaxial car speaker
25W 35W 45W
75W 105W 135W
67Hz-21kHz
85Hz-21kHz 75Hz-21kHz
3.0ohms 3.0ohms 3.0ohms
91dB 92dB 92dB
5-1/8" (129mm)
3-7/16" (87mm) 4-1/16" (102.4mm)
4-1/2" (113.6mm)
3" (75.5mm) 3-11/16" (92.1mm)
2-5/16" (57.4mm)
1-13/16" (45.5mm) 2-3/16" (54.9mm)
1-7/16" (35.7mm) 1-7/8" (47.3mm) 1-15/16" (48mm)
Reference 307F Reference 407F Reference 507F
Haut-parleur automobile coaxial hautes Haut-parleur automobile coaxial hautes Haut-parleur automobile coaxial hautes
performances 87mm (3-1/2") performances 100 mm (4") performances 130mm (5-1/4")
25W 35W 45W
75W 105W 135W
67Hz-21kHz
85Hz-21kHz 75Hz-21kHz
3.0ohms 3.0ohms 3.0ohms
91dB 92dB 92dB
5-1/8" (129mm)
3-7/16" (87mm) 4-1/16" (102.4mm)
4-1/2" (113.6mm)
3" (75.5mm) 3-11/16" (92.1mm)
1-13/16" (45.5mm) 2-5/16" (57.4mm)
2-3/16" (54.9mm)
1-7/16" (35.7mm) 1-7/8" (47.3mm) 1-15/16" (48mm)
Reference 307F Reference 407F Reference 507F
Altavoz para automóvil coaxial de Altavoz para automóvil coaxial de Altavoz para automóvil coaxial de alto
alto rendimiento de 3-1/2" (87 mm) alto rendimiento de 4" (100 mm) rendimiento de 5-1/4" (130 mm)
45W
25W 35W
135W
75W 105W
67Hz-21kHz
85Hz-21kHz 75Hz-21kHz
3.0ohms
3.0ohms 3.0ohms
92dB
91dB 92dB
5-1/8" (129mm)
3-7/16" (87mm) 4-1/16" (102.4mm)
4-1/2" (113.6mm)
3" (75.5mm) 3-11/16" (92.1mm)
2-5/16" (57.4mm)
1-13/16" (45.5mm) 2-3/16" (54.9mm)
1-15/16" (48mm)
1-7/16" (35.7mm) 1-7/8" (47.3mm)
CA_Infinity Reference Speaker Gen 4_OM_US_CR_V6
Reference 467F Reference 687F Reference 507CF
4" x 6" high performance coaxial 6" x 8" high performance coaxial 5-1/4" (130mm) high performance
car speaker car speaker component speaker system
45W 60W 65W
135W 180W 195W
75Hz-21kHz 49Hz-21kHz 67Hz-21kHz
3.0ohms 3.0ohms 3.0ohms
92dB 93dB 93dB
6-3/16" X 3-15/16" 8-11/16" X 5-5/8" 5-1/8" (129mm)
(157mm X 99.5mm) (220mm X 142.2mm)
5-9/16" X 3-3/8" 7-1/4" X 5" 4-1/2" (113.6mm)
(140.4mm X 85.1mm) (182.6mm X 125.6mm)
2-3/16" (55.4mm) 2-15/16" (74.2mm) 2-3/16" (55mm)
1-7/8" (46.7mm) 2-7/16" (61.1mm) 1-15/16" (48mm)
Reference 467F Reference 687F Reference 507CF
Haut-parleur automobile coaxial hautes Haut-parleur automobile coaxial hautes Système haut-parleur automobile compo-
performances 152 mm x 229 mm (4" x 6") performances 152 mm x 229 mm (6" x 8") sant hautes performances 130 mm (5-1/4")
45W 60W 65W
135W 180W 195W
75Hz-21kHz 49Hz-21kHz 67Hz-21kHz
3.0ohms 3.0ohms 3.0ohms
92dB 93dB 93dB
6-3/16" X 3-15/16" 8-11/16" X 5-5/8" 5-1/8" (129mm)
(157mm X 99.5mm) (220mm X 142.2mm)
5-9/16" X 3-3/8" 7-1/4" X 5" 4-1/2" (113.6mm)
(140.4mm X 85.1mm) (182.6mm X 125.6mm)
2-3/16" (55.4mm) 2-15/16" (74.2mm) 2-3/16" (55mm)
1-7/8" (46.7mm) 2-7/16" (61.1mm) 1-15/16" (48mm)
Reference 467F Reference 687F Reference 507CF
Altavoz para automóvil coaxial de Altavoz para automóvil coaxial de Altavoz para automóvil de componentes
de alto rendimiento de 5-1/4" (130 mm)
alto rendimiento de 4" x 9" alto rendimiento de 6" x 8"
65W
45W 60W
195W
135W 180W
67Hz-21kHz
75Hz-21kHz 49Hz-21kHz
3.0ohms
3.0ohms 3.0ohms
93dB
92dB 93dB
5-1/8" (129mm)
6-3/16" X 3-15/16" 8-11/16" X 5-5/8"
(157mm X 99.5mm) (220mm X 142.2mm)
4-1/2" (113.6mm)
5-9/16" X 3-3/8" 7-1/4" X 5"
(140.4mm X 85.1mm) (182.6mm X 125.6mm)
2-3/16" (55mm)
2-3/16" (55.4mm) 2-15/16" (74.2mm)
1-15/16" (48mm)
1-7/8" (46.7mm) 2-7/16" (61.1mm)
© 2023 HARMAN International Industries, Incorporated. All rights reserved.
Infinity is a trademark of HARMAN International Industries, Incorporated, registered in the United States and/or other countries.
Features, specifications and appearance are subject to change without notice.
Reference 607CF Reference 697CF Reference 757T
6-1/2" (160mm) high performance 6" x 9" high performance 3/4" (19mm) high performance
component speaker system component speaker system component tweeter
90W 125W 45W
270W 375W 135W
53Hz-21kHz 46Hz - 21kHz 2.5kHz - 21kHz
3.0ohms 3.0ohms 3.0ohms
93dB 93dB 93dB
6-1/4" (158mm) 9-5/16" X 6-7/16" 2-1/4" (56mm)
(236.5mm X 163mm)
5" (127mm) 8-1/2" X 5-3/4" 1-5/8" (40mm)
(214.6mm X 144.6mm)
2-9/16" (64.8mm) 3-1/2" (88mm) 1-7/16" (36.1mm)
2-1/16" (51.5mm) 3-1/8" (77.8mm) 13/16" (20mm)
Reference 607CF Reference 697CF Reference 757T
Système haut-parleur automobile compo- Système haut-parleur composant hautes Haut-parleur aigu composant hautes
sant hautes performances 160mm (6-1/2") performances 152 mm x 229 mm (6" x 9") performances 19 mm (3/4" )
90W 125W
45W
270W 375W 135W
53Hz-21kHz 46Hz - 21kHz 2.5kHz - 21kHz
3.0ohms 3.0ohms
3.0ohms
93dB 93dB 93dB
6-1/4" (158mm) 9-5/16" X 6-7/16" 2-1/4" (56mm)
(236.5mm X 163mm)
5" (127mm) 8-1/2" X 5-3/4" 1-5/8" (40mm)
(214.6mm X 144.6mm)
2-9/16" (64.8mm) 3-1/2" (88mm) 1-7/16" (36.1mm)
2-1/16" (51.5mm) 3-1/8" (77.8mm)
13/16" (20mm)
Reference 607CF Reference 697CF Reference 757T
Altavoz para automóvil de componentes Altavoz para automóvil de componentes Altavoz de agudos de componentes de
de alto rendimiento de 6-1/2" (160 mm) de alto rendimiento de 6" x 9" alto rendimiento 3/4" (19 mm)
90W 125W 45W
270W 375W 135W
53Hz-21kHz 46Hz - 21kHz 2.5kHz - 21kHz
3.0ohms 3.0ohms 3.0ohms
93dB 93dB 93dB
6-1/4" (158mm) 2-1/4" (56mm)
9-5/16" X 6-7/16"
(236.5mm X 163mm)
5" (127mm) 1-5/8" (40mm)
8-1/2" X 5-3/4"
(214.6mm X 144.6mm)
2-9/16" (64.8mm) 1-7/16" (36.1mm)
3-1/2" (88mm)
2-1/16" (51.5mm) 3-1/8" (77.8mm) 13/16" (20mm)
Reference 607FSL Reference 697F
6-1/2" (160mm) high performance 6" x 9" high performance
EZFit coaxial car speaker coaxial car speaker
55W 100W
165W 300W
57Hz-21kHz 46Hz - 20kHz
3.0ohms 3.0ohms
93dB 94dB
6-1/4" (158mm) 9-5/16" X 6-7/16"
(236.5mm X 163mm)
4-7/8" (123.4mm) 8-1/2" X 5-3/4"
(214.6mm X 144.6mm)
2-1/8" (52.6mm) 3-5/8" (91.8mm)
1-13/16" (44.6mm) 3-1/8" (77.8mm)
Reference 607FSL Reference 697F
Haut-parleur automobile coaxial EZFit Haut-parleur automobile coaxial hautes
hautes performances 160 mm (6-1/2") performances 152 mm x 229 mm (6" x 9")
55W 100W
165W 300W
57Hz-21kHz 46Hz - 20kHz
3.0ohms 3.0ohms
93dB 94dB
6-1/4" (158mm) 9-5/16" X 6-7/16"
(236.5mm X 163mm)
4-7/8" (123.4mm) 8-1/2" X 5-3/4"
(214.6mm X 144.6mm)
2-1/8" (52.6mm) 3-5/8" (91.8mm)
1-13/16" (44.6mm) 3-1/8" (77.8mm)
Reference 607FSL Reference 697F
Altavoz para automóvil coaxial EZFit de Altavoz para automóvil coaxial de
alto rendimiento de 9-1/2" (160 mm) alto rendimiento de 6" x 9"
55W
100W
165W 300W
57Hz-21kHz 46Hz - 20kHz
3.0ohms
3.0ohms
93dB 94dB
6-1/4" (158mm)
9-5/16" X 6-7/16"
(236.5mm X 163mm)
4-7/8" (123.4mm)
8-1/2" X 5-3/4"
(214.6mm X 144.6mm)
2-1/8" (52.6mm)
3-5/8" (91.8mm)
1-13/16" (44.6mm) 3-1/8" (77.8mm)
