Introduction
Multiprotocol receiver compatible with MOTION transmitters. Codifies the transmitter signal in two different protocols
according to its configuration: Wiegand 26 and Wiegand 37.
Installation and connections
Attach the rear part of the housing to the wall using the plugs and screws supplied. Pass the cables through the bottom of
the receiver. Connect the power cables to the terminals marked on the mother board, as indicated. Fix the receiver front
to the rear part using the screws supplied.
jcmtechnologies
4
