FireWare Cumulus
3.

Overview of the parts and technical information

Parts:
1. Handles
2. Smoke jet
3. Storz coupling for connecting
hose adapters or an aiming piece
4. Smoke fluid holder
5. Ventilation holes
6. 5 litre FireWare Medium Smoke
Fluid
7. Remote control with 10 metre
cable
8. Electrical outlet for other devices
9. Plastic case (60*40*32.5)
Options / accessories:
008-002-002
008-012-005
008-012-006
008-012-007
009-030-001
009-030-002
009-030-003
009-030-005
009-030-006
Technical information:
Power
Voltage
Warm up time
Dimensions
Weight
Tank capacity
Adjusting output
Smoke time
Protection against
overheat
14 FireWare Cumulus
1
2
3
Wireless XLR remote, for wireless control of the Cumulus.
Adapter Storz 52 to 65, for connecting your own Storz hose.
Hose adapter Storz 65 to round 100 mm, this can be connected
to above-mentioned adapter to afterwards connect a smoke
hose from FireWare.
Aiming Piece Cumulus/Stratus, to aim the smoke for example
vertically. This aiming piece can be connected directly to the
Storz 52 exit of the Cumulus.
FireWare Light Smoke fluid
FireWare Medium Smoke fluid
FireWare Heavy Smoke fluid
FireWare Outdoor Smoke fluid
FireWare Burning Smell Smoke fluid
1300 Watt
230 V/50 Hz of 120 V/60 Hz
7 minutes
50,3 x 25,0 x 24,5 centimeters
10,5 kg
5 l
Adjustable in steps of 1% (0-99%)
At 100% approximately 40 seconds
At 48% and less continuously
Heat blockage/thermostat pump/heat switch
1
4
8
5
7
9
6
