READ AND SAVE THESE INSTRUCTIONS
CAUTION: Read and follow all instructions before operating fan. Do not use fan if any part is
damaged or missing.
WARNING: - To reduce the risk of fire or electrical shock, do not expose to water or rain.
- To reduce the risk of fire or electrical shock, do not use this fan with any solid state speed
control device.
- Automatically operated device - to reduce the risk of injury disconnect from power supply
before servicing.
- Do not operate any fan with a damaged cord or plug. Discard fan or return to an authorized
service facility for examination and/or repair.
- Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar
coverings. Do not route cord under furniture or appliances. Arrange cord away from traffic area
and where it will not be tripped over.
- The appliance does not apply to be used in locations where special conditions prevail, such as
the presence of a corrosive or explosive atmosphere (dust, vapour or gas).
- This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
- Children should be supervised to ensure that they do not play with the appliance.
RULES FOR SAFE OPERATION:
1. Never insert fingers or any other objects through the
grill guard when fan is in operation.
2. Disconnect the fan when moving from one location
to another.
3. Disconnect the fan when removing guards for
cleaning.
4. Be sure fan is on a stable, flat surface when in
operation.
5. Do not use fan in windows. Rain and moisture
may create electrical hazard.
6. Do not place the fan near an open flame, cooking
or heating appliance, or hot surface.
7. This fan should not be operated outside.
CAUTION: Do not alter the fan's assembly.
WARNING: Be sure front and rear guard screw are
completely screwed down in locking position before
operation.
S3 TYPE ASSEMBLY INSTRUCTION
1. Attach CAST COUPLING to the BASE with
the 4 screws as shown.
2. Loosen KNOB on COUPLING and extend
INNER TUBE to desired height.
3. Slide COVER RING down the OUTER TUBE
to rest on top of the BASE.
CAUTION: KNOB must be fully tightened before
assembling the FAN HEAD to the INNER TUBE.
4. Fan head and supporting brace come fully
assembed.
Fan
Support tube
Mounting plate
Nut
Inner Tube
Screws
Knob
Outer Tube
Cover
ring
Screws
Coupling
Base
Nut
5. Place the FRONT MOUNTING PLATE and the REAR MOUNTING PLATE to the
center hole of the SUPPORT TUBE. Tighten the screw as shown.
6. Firmly attach SUPPORTING TUBE to the INNER TUBE using the 2 mounting
screws and spring washers provided.
OPERATING INSTRUCTIONS
TO ADJUST AIRFLOW UPWARD OR DOWNWARD: Tilt fan head to the desired
angle. This high velocity fan can be used alone or in conjunction with air conditioning.
Rotating the fan head upward serves to pull air from the floor and circulate it
throughout the entire room.
SPEED CONTROL: Rotate SWITCH to LOW, MEDIUM and HIGH speeds for
respective air velocity.
It is normal for the motor to feel warm to touch after continuous operation.
This fan features a thermostat that will automatically shut off should it overheat for any
reason. If this happens, immediately unplug the fan from the outlet.
CLEANING
WARNING: Unplug from electrical supply source before cleaning.
1. Use soft damp cloth to clean, then wipe with dry cloth.
2. Do not use a cleaning solution that is harmful to paints or plastics.
3. Do not bend the blades.
4. Put several drops of sewing machine oil into the oil ways on the front and rear shells
at regular intervals (Once after 3 months of 24 hour use or 6 months of regular use).
IMPORTANT: SURGES IN ELECTRICAL POWER OR EXCESSIVE HEAT MAY
CAUSE THE FAN TO TURN OFF. WAIT APPROXIMATELY 15 MINUTES FOR THE
FAN TO RESUME OPERATION.
MODEL: FE2-50S3dO(5) ITEM: EA289
RATING: 120V~ 60Hz 1.2A
