Sauder 412871 Mode D'emploi

Sauder 412871 Mode D'emploi

Masquer les pouces

Table des Matières

412871
Panel TV Stand
Regent Place Collection
PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English .................... Page 1-18
Français ...............Pages 19-21
Made in the USA
Espanol .............Páginas 22-24
Archbold, OH
Lot #: 345981
Date Purchased: ____________________
07 / 11 / 12
Table des Matières
loading

Manuels Connexes pour Sauder 412871

Sommaire des Matières pour Sauder 412871

  • Page 1 412871 Panel TV Stand Regent Place Collection NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE CONTACT US PLEASE READ AND KEEP FOR FUTURE REFERENCE. BEFORE RETURNING English ....Page 1-18 YOUR UNIT TO THE STORE Français ....Pages 19-21 Made in the USA 1-800-523-3987 Espanol .....Páginas 22-24...
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 95 pounds. Never use with a TV that weighs more.

  • Page 3: Part Identification

    RIGHT END SMALL ADJUSTABLE SHELF LEFT END LONG SKIRT RIGHT UPRIGHT SHORT SKIRT LEFT UPRIGHT TOP MOLDING FRONT BRACE BOTTOM SHORT BRACE BACK SIDE BRACE OUTER BACK INNER PLINTH DOOR OUTER PLINTH LARGE ADJUSTABLE SHELF 412871 www.sauder.com/services Page 3...
  • Page 4 GOLD 1" MACHINE SCREW - 2 BLACK 9/16" LARGE HEAD SCREW - 37 BLACK 1/2" FLAT HEAD SCREW - 8 NAIL - 20 Screws are shown actual size. You may receive extra hardware with your unit. Page 4 www.sauder.com/services 412871...
  • Page 5 Assemble your unit on a carpeted fl oor or on the empty carton to avoid scratching your unit or the fl oor. ® To begin assembly, push a SAUDER TWIST-LOCK FASTENER (U) into the large holes in the ENDS (A and B). Repeat this step for the UPRIGHTS (C and D).
  • Page 6 Do not tighten the HIDDEN CAMS in this step. Arrow (2 used) Arrow Insert the CAM DOWEL into the HIDDEN CAM. Push two HIDDEN CAMS (V2) into the SHORT BRACE (Q). Then, insert a CAM DOWEL (W2) into each HIDDEN CAM. Page 6 www.sauder.com/services 412871...
  • Page 7 Finished surface Curved edge SILVER 1-1/8" FLAT HEAD SCREW (6 used in this step) Fasten the TOP MOLDING (O) to the TOP (E). Use six SILVER 1-1/8" FLAT HEAD SCREWS (GG). 412871 www.sauder.com/services Page 7...
  • Page 8 ® How to use the SAUDER TWIST-LOCK FASTENER 1. Insert the dowel end of the FASTENER into the hole of the adjoining part. NOTE: The dowel end of the FASTENER must remain fully inserted in the hole of the adjoining part while locking the FASTENER.
  • Page 9 F i n Insert eight METAL PINS (CC) into the OUTER BACKS (H). Insert the METAL PINS (CC) in one end of the OUTER BACKS (H) into the holes in the UPRIGHTS (C and D). 412871 www.sauder.com/services Page 9...
  • Page 10 Fasten the ENDS (A and B) to the TOP (E). Tighten four TWIST-LOCK ® FASTENERS. NOTE: Be sure the METAL PINS in the OUTER BACKS (H) insert into the holes in the ENDS (A and B). Page 10 www.sauder.com/services 412871...
  • Page 11 Tighten Arrow Risk of damage or injury. Hidden Cams must be completely Arrow Maximum tightened. Hidden 210 degrees Cams that are not completely tightened Minimum may loosen, and parts 190 degrees may separate. To completely tighten: 412871 www.sauder.com/services Page 11...
  • Page 12 (18 used for the METAL BRACKETS) Fasten eighteen METAL BRACKETS (Y) to the BRACES (P and R). Use eighteen BLACK 9/16” LARGE HEAD SCREWS (II). NOTE: Be sure the BRACKETS are even with the edges of the BRACES. Page 12 www.sauder.com/services 412871...
  • Page 13 Fasten the FRONT BRACES (P) to the SHORT BRACE (Q). Use two BLACK 1-7/8" FLAT HEAD SCREWS (FF). Fasten the SIDE BRACES (R) to the BOTTOM (F) and FRONT BRACES (P). Use ten BLACK 9/16" LARGE HEAD SCREWS (II). 412871 www.sauder.com/services...
  • Page 14 Fasten the LARGE METAL BRACKET (X) to the BOTTOM (F). Use a BLACK 9/16" LARGE HEAD SCREW (II). Now, insert the SKIRTS (L and M) into the notches of the PLINTHS. NOTE: Be sure the LONG SKIRT is positioned in front of the LARGE METAL BRACKET. Page 14 www.sauder.com/services 412871...
  • Page 15 Make equal margins along all four edges of the BACK (G). Push on opposite corners of your unit if needed to make it “square”. Fasten the BACK (G) to your unit using the NAILS (KK). NOTE: Perforations have been provided for access through the BACK. Carefully cut out the holes needed. 412871 www.sauder.com/services Page 15...
  • Page 16 Peel a FELT DISC from the FELT DISC CARD (BB) and stick it on the DOOR where it comes in contact with the RIGHT UPRIGHT (C). Fasten a KNOB (AA) to the DOOR (I). Use a GOLD 1" MACHINE SCREW (HH). Repeat this step for the other DOOR (I). Page 16 www.sauder.com/services 412871...
  • Page 17 Tighten the screws after making adjustments. To adjust the DOORS in or out (depth), loosen the mounting screw one turn and move the DOOR in or out, as needed. Tighten the mounting screw after making adjustments. 412871 www.sauder.com/services Page 17...
  • Page 18 NOTE: This is a permanent label intended to last for the life of the product. Once applied, do not try to remove it. NOTE: Please read the back pages of the instruction booklet for important safety information. This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. Page 18 www.sauder.com/services 412871...

  • Page 19: Meuble Téléviseur À Écran Plat

    PLATE 28 mm ........14 et conserver le livret ENTRETOISE LATÉRALE ....2 pour future référence. HH VIS DORÉE À MÉTAUX 25 mm ..2 Pour contacter Sauder PLINTHE INTERNE ......2 VIS NOIRE TÊTE LARGE 14 mm ..37 en ce qui concerne cet PLINTHE EXTERNE ......2 VIS NOIRE TÊTE PLATE 13 mm ..8...
  • Page 20 ! Fixer les MONTANTS (C et D) au DESSUS (E). Serrer quatre FIXATIONS TWIST-LOCK®. • Cette unité Sauder est conçue pour les téléviseurs pesant moins de 43 kg. Ne jamais utiliser avec des téléviseurs plus lourds. ÉTAPE 5 •...
  • Page 21 fi gurant sur les pages arrière du manuel d’instructions. Utiliser les vis fournies avec les CHARNIÈRES. Voir Ceci complète l'assemblage. Nettoyer à l’aide d’une l'étape suivante pour réglages de la porte. encaustique pour meubles ou d’un chiffon humide. Essuyer. 412871 www.sauder.com/services Page 21...

  • Page 22: Lista De Partes

    CABEZA PERDIDA de 28 mm ..14 PLINTO INTERIOR ......2 en contacto con HH TORNILLO DORADO PARA PLINTO EXTERIOR ......2 Sauder en cuanto a METAL de 25 mm ......2 esta unidad, refi érase TORNILLO NEGRO DE al número de lote y CABEZA GRANDE de 14 mm ..37...
  • Page 23 - antes de comenzar el ensamblaje! un destornillador Phillips (cruz). • Esta unidad Sauder está diseñada para ser usada con Fije los PARALES (C y D) al PANEL SUPERIOR (E). televisores cuyo peso sea inferior a 43 Kg. Nunca la use Apriete cuatro SUJETADORES TWIST-LOCK®.
  • Page 24 Fije una PUERTA (I) al EXTREMO DERECHO (A). Esto completa el ensamblaje. Limpie con su pulimento para Utilice los tornillos provistos de las BISAGRAS. Consulte muebles preferido o un paño húmedo. Seque con un paño. el próximo paso para ajustar las puertas. Page 24 www.sauder.com/services 412871...
  • Page 25 équipé. • Blessure physique. Le mobilier peut être mobilier. très lourd. • Ne pas pousser le mobilier, surtout sur la moquette. Se faire aider par une autre personne pour soulever l’élément et le mettre en place. 412871 www.sauder.com/services Page 25...
  • Page 26 • Lesión física. El mobiliario puede ser • No empuje la unidad, especialmente muy pesado. sobre un piso alfombrado. Pide la ayuda de otra persona en levantar la unidad y colocarla en lugar. Page 26 www.sauder.com/services 412871...

  • Page 27: Garantie Limitée De 5 Ans

    4. La présente garantie ne s’applique qu’aux défauts garantis qui se produisent des composantes de mobilier Sauder. Le mot « défaut », tel qu’il est utilisé sous pour la première fois et qui sont signalés à Sauder dans les limites de ouverture les termes de la présente garantie, comprend les imperfections des pièces qui...
  • Page 28 Archbold, Ohio, where it all began. Certifi cate of Conformity The Sauder name on the box ensures that 1. This certifi cate applies to the Sauder Woodworking Product indentifi ed by this Instruction Book. the item you have purchased is made with 2.
