User's manual
OPERATING INSTRUCTIONS
DMX 512 Addressing
Dip Switch setting
Each Dip switch has an address based on binary code.
Dip Switch No.
1
2
Value
1
2
Select the desired address by adding the On values of all the
Dip switches.
Dip Switch no.10 is not used with DMX, it is normally used to
select some functions, i.e. Master/Slave, Sound activation,
etc.
16 channels are assigned to each of the 12 fixtures.
The Dip switches are set as per the chart below:
Scanners
Channels
1
1~16
2
17~32
3
33~48
4
49~64
5
65~80
6
81~96
7
97~112
8
113~128
9
129~144
10
145~160
11
161~176
12
177~192
Note: When addressing your fixtures, follow the starting
address indicated in these operating instructions and not the
addressing found in the user manual of your fixtures.
Scene Programming
• Press and hold the Program button down for three seconds
to activate program mode. The LED next to "Program"
blinks, indicating the program has been started.
• Select a fixture to program by pressing any or all of the
Scanner buttons from 1 to 12.
• Adjust the faders to the desired output level for all channels
(i.e. Color, Gobo, Pan, Tilt, etc.) of the selected fixture or
fixtures. Press Page Select A/B if the fixture has more than
8 channels. When selecting from Page A to B, you have to
move the sliders to activate the channels.
• If you have set the fixture to your liking and you wish to
program another fixture, press the Scanner button you
have just finished adjusting again.
• This will hold the fixture in its final configuration. Select
another fixture/s by pressing the target Scanner button and
proceed to fader adjustments to achieve the settings you
desire.
• Repeat steps 2 and 3 until you have set all the fixtures the
way you like.
• When an entire scene is set to your liking, press and
release the MIDI/Add button.
• Select the desired bank to store the scene using the Up
and Down Bank selection buttons. There are 30 banks in
which you can store up to 8 scenes per bank, for a total of
240 scenes.
2
3
4
5
6
7
8
4
8
16
32 64 128 256
Dip switches on
0 or 1 based on scanner
1,5
1,6
1,5,6
1,7
1,5,7
1,6,7
1,5,6,7
1,8
1,5,8
1,6,8
1,5,6,8
• Then press a Scene button 1~8 to store the scene. All LEDs
blink 3 times. The LCD will display the bank and scene
where your scene was stored.
• Repeat steps 2~8 to record your desired scenes.
• You can copy the settings from one scanner button to
another in case you want to add more fixtures to your show.
Just press and hold down the scanner button you want to
9
copy, and then press the scanner button you want to copy
to.
• To exit the programming mode, press and hold the
Program button down for 3 seconds. (When you exit
programming, the Blackout LED is on, press the Blackout
button to deactivate the blackout function.)
Scene Editing
This function allows you to make changes in a previously
programmed scene.
• Press the Program button for three seconds to enter the
program mode.
• Use the Up and Down Bank buttons to select the bank that
stores the scene you wish to edit.
• Select the scene you want to edit by pressing its Scene
button.
• Use the faders to make your desired adjustments.
• Press the MIDI/Add button, followed by the Scene button
that corresponds to the scene you selected earlier,
otherwise you may accidentally record over an existing
scene.
Copy Scene
This allows you to copy the settings from one scene to
another.
• Press the Program button for three seconds to enter the
programming mode.
• Use the Up and Down Bank buttons to locate the bank in
which the scene to copy is stored.
• Select the scene you want to copy by pressing the
corresponding Scene button.
• Use the Up and Down Bank buttons to select the bank
where you want to store the copied scene.
• Press MIDI/Add, followed by the Scene button in which you
want to copy to.
Delete Scene
This function will reset all DMX channels incorporated within
a scene to 0.
• Select the scene you wish to delete.
• While pressing and holding the Auto/Del button down,
press the Scene button (1 to 8) you want to delete.
Erase all Scenes
This will erase all scenes in all banks.
All scenes are reset to 0.
• Press and hold the Program and Bank Down buttons down
while turning the power off.
• Reconnect the power, all scenes should be erased!
Copy Bank
This function enables you to copy the settings of one bank to
another bank.
• Press and hold the Program button down for three seconds
to activate the programming mode.
• Select the bank you want to copy.
• Press and release the MIDI/Add button.
• Select the bank into which you want to copy the settings.
• Press the Music /Bank-Copy button. The LCD display will
eagletone.com
EAGLETONE DMX DISCONTROL 192
