INTRODUCTION
Thank you for purchasing the SubZero DB20 Dynamic Broadcast
Microphone. To get the most out of your products, please read this
manual carefully.
BOX CONTENTS
• 1 x DB20 Dynamic Broadcast Microphone
• 1 x Windscreen
• 1 x User Manual
PRODUCT FEATURES
• Dynamic Microphone specifically for Boardcasting
• Super-directional Polar Pattern focus on your voice capture
• -53dB+/-2B Dynamic Sensitivity (0dB=1V/Pa at 1kHz)
• 135dB Max. Input SPL (at 1kHz ≤ 1% T.H.D)
SPECIFICATIONS
Element: . . . . . . . . . . . . . . . . . Dynamic
Polar Pattern . . . . . . . . . . . . . . Cardioid
Frequency Response . . . . . . . 40-20kHz
Sensitivity . . . . . . . . . . . . . . . . -53dB+/-2B (0dB=1V/Pa at 1kHz)
Max Input SPL . . . . . . . . . . . . 135dB (at 1kHz<1% T.H.D)
S/N Ratio . . . . . . . . . . . . . . . . 78dB
Weight . . . . . . . . . . . . . . . . . . 860g
Dimensions
(Diam x W x H) . . . . . . . . . . . . 65 x 105 x 182mm
Output Connector . . . . . . . . . XLR
–20
–30
–40
–50
–60
20 50
3
100 200 200
Frequency Response
1
FUNCTIONS
1. XLR port
Connect your XLR cable here.
2. Capsule
Aim the grille at your sound source to capture every detail.
1K 2K 5K 10K
0
330
300
270
240
20KHz
210
180
Super-directional
(at 1kHz)
2
30
60
90
120
150
