Scanstrut Ventura Serie Instructions D'installation

SC-V-P1
Ventura Series
Dual 125V 20A AC Outlet
Electrical Information
& Installation Instructions
scanstrut.com
EN READ THESE INSTRUCTIONS BEFORE INSTALLING THE PRODUCT
ES LEA ESTAS INSTRUCCIONES ANTES DE INSTALAR EL PRODUCTO
FR-CA LIRE CES INSTRUCTIONS AVANT D'INSTALLER LE PRODUIT
Technical Information
Rating 20A 125V
12AWG Triplex Recommended
Cable
Copper cable must be used for installation
• Grounded duplex NEMA 5-20R - UL & CSA-listed
• Screw terminals
Receptacle
• Replace receptacle only with Scanstrut part
number SC-UTIL-P-006285 (Qualtek 740W-F/06)
Tools Required
Drill Bit
Drill Jigsaw
ø 2.5mm (3/32") | ø 8mm (5/16") | ø 12.5mm (1/2")
Pilot Drill
Screwdrivers
Material Fixing
Size
PH1 | PH2 | T15
Soft Material 2.5mm
eg. plywood (3/32")
Included
Silicone or
Hard Material
4x No.6 Screws
Automotive Sealant 3mm
eg. fiberglass,
(1/8")
hardwood, acrylic
Recommended
File
Flanged M4 Panhead
Metal eg. steel, 4mm
Bolts, Washers and
aluminium (5/32")
Nyloc Nuts
(Not included)
For the latest tech info visit
scanstrut.com
UK / EMEA / APAC USA
Scanstrut Ltd, 14 Dart Business Park, Scanstrut Inc. 7 Pequot Park Rd,
Clyst St. George, Exeter, EX3 0QH #303 Westbrook, CT 06498
RevA OEM-INST005766
Parts List
1 x Front Housing 1 x Rear Housing 1 x Receptacle 1 x Rubber Grommet
Installation This product must be mounted strictly in accordance with the provided mounting template
and must not be installed in any location where submersion or partial submersion may occur.
• Cut out template • Jigsaw inside of the cutting boundary.
1 2
• Tape to mounting surface DO NOT exceed boundary area.
• Use template to drill: • Test fit the product - if needed, file the cut
4x ø2.5mm (3/32") holes area until a tight fit is achieved.
3x ø8mm (5/16") holes • Clean mounting surface.
2x ø12.5mm (1/2") holes
• Strip wires as required to suitable length
• Fit grommet to rear housing.
4 5
• Cut grommet cross hairs to required size (minimum 7mm (0.28"), then connect and
secure to receptacle terminals:
for chosen installation cable.
• Slide length of installation cable • Green Ground wire - green screw
• White Neutral wire - silver screws
through grommet - cable must
not be connected to • Black Hot/Line wire - gold screws
live power source.
1
2
3
• Choose the desired installation
7 • Slide rear housing over wired 8
receptacle. cable rear exit orientation.
• Place the cable strain-relief
• Secure to housing assembly
with 3x 3mm PH1 screws. bracket over the protruding
cable sheath.
• Clamp cable to the rear
housing with the 2x
remaining 3mm PH1 screws.
• Professional electrician installation only for
10
connecting receptacle wiring to onboard 125V system.
• Connect to a breaker (GFCI recommended).
1 x Cable Strain 4 x No. 6 Flange Screws
1 x Torx Bolt 5 x 3mm Screws
Relief Bracket
• Remove receptacle
3
(1x Torx T15 bolt)
from front lid assembly.
• Pull through the mounting
6
surface and fix the wired
receptacle to the front
housing with the
Torx T15 screw.
GN
WH
• Ensure the ground terminal
is orientated correctly.
BK
OR
• Apply silicone/automotive sealant to the
9
4x No.6 PH2 flanged mounting screws.
• Secure the housing assembly to the
mounting surface - DO NOT over tighten
the screws.
If daisy chaining connection to multiple
receptacles, the slot features in the
strain-relief bracket can be used to
secure an additional cable to it with a
suitably sized cable tie (not included).
• Only daisy chain to circuit with other 20A duplex receptacles. Do not connect to 15A circuit.
• If daisy chaining to multiple 20A receptacles in a circuit, utilize appropriate wire gauge cable
size per Industry Standards.
• If daisy chaining to multiple 20A receptacles, the first receptacle in the circuit must be
GFCI protected.
Drilling Template Scale 1:1
WARNING:
CHECK SCALE
50mm
2"
69.0mm (2.72")
38.0mm (1.50")
31.7mm (1.25")
41.8mm (1.65")
43.0mm (1.69")
