ASSEMBLY INSTRUCTIONS
1. Place chair seat (B) on a soft, clean
surface and loosely attach backrest (A)
to seat (B) with 2 inner hexagonal
screws (BB), 2 large washers (DD) and
2 lock washers (FF).
Hardware Used
M8 60 Inner Hexagonal Screw
20 Large Washer
8
8 Lock Washer
2. Loosely attach backrest (A) to left arm
and right arm of seat (B) with 2 inner
hexagonal screws (BB), 2 washers
(CC) and 2 lock washers (FF).
Hardware Used
M8 60 Inner Hexagonal Screw
8 Washer
8 Lock Washer
2
2
2
2
2
2
4
1
2
