Sommaire des Matières pour TDK-Lambda DPX40-24WD12
Page 1
TDK-Lambda DPX40-24WD12 DC-DC Converter In Stock Qty Available: 1 Used and in Excellent Condition Open Web Page https://www.artisantg.com/54662-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
Page 2
ENGLISH READ SAFETY INSTRUCTIONS Servicing: These products are not customer serviceable. TDK-Lambda UK LTD. and their authorised agents only are permitted to carry out repairs. Critical Components: These products are not authorised for use as critical components in nuclear control systems, life support systems or equipment for use in hazardous environments without the express written approval of the Managing Director of TDK-Lambda EMEA.
Page 3
DPX Series Product HANDBOOK HOT SURFACE External Hot Surfaces: In accordance with local regulations for Health and Safety at work, manufacturers have an obligation to protect service engineers as well as users. In order to comply with this, a label must be fitted to these products which is clearly visible to service personnel accessing the overall equipment, and which legibly warns that surfaces of these products may be hot and must not be touched when the products are in operation.
Page 4
DEUTSCH LESEN SIE DIE SICHERHEITSVORSCHRIFTEN Wartung: Diese Produkte können nicht durch den Kunden gewartet werden. Nur TDK-Lambda UK LTD. und deren zugelassene Vertriebshändler sind zur Durchführung von Reparaturen berechtigt. Kritische Komponenten: Diese Produkte sind nicht für die Verwendung als kritische Komponenten in nuklearen Kontrollsystemen, Lebenserhaltungssystemen oder Geräten in gefährlichen Umgebungen geeignet, sofern dies nicht...
Page 5
DPX Series Product HANDBOOK HEISSE OBERFLÄCHEN Äußere heiße Oberflächen: In Übereinstimmung mit den regionalen Bestimmungen für Gesundheit und Sicherheit bei der Arbeit ist der Hersteller für den Schutz von Wartungspersonal und Benutzern verantwortlich. Um diesen Bestimmungen gerecht zu werden, muss auf den Produkten ein Label angebracht werden, das deutlich sichtbar für das Wartungspersonal mit Zugriff auf die gesamte Anlage ist, und das gut lesbar auf die eventuell heiße Oberfläche des Gerätes hinweist und das Berühren des Produktes in Betrieb untersagt.
Page 6
FRANÇAIS LIRE LES CONSIGNES DE SECURITE Entretien: Ces produits ne peuvent pas être réparés par le client. Seul, TDK-Lambda UK LTD et ses agents agréés sont autorisés à effectuer des réparations. Composants critiques: Ces produits ne doivent pas être utilisés en tant que composants critiques dans des systèmes de commande nucléaire, dans des systèmes de sauvetage ou dans des équipements utilisés dans des environnements...
Page 7
DPX Series Product HANDBOOK SURFACE CHAUDE Surfaces chaudes extérieures: Conformément aux réglementations locales concernant la santé et la sécurité sur les lieux de travail, les fabricants doivent protéger les techniciens d'entretien et les utilisateurs. Pour cela, une plaque signalétique doit être installée sur ces produits, et cette plaque doit être bien visible pour les techniciens d'entretien intervenant sur l'équipement, et elle doit indiquer de manière bien visible que les surfaces de ces produits peuvent être chaudes et qu'elles ne doivent pas être touchées lorsque les produits fonctionnent.
Page 8
Manutenzione: Il cliente non può eseguire alcuna manutenzione su questi prodotti. L'esecuzione delle eventuali riparazioni è consentita solo a TDK-Lambda UK LTD e ai suoi agenti autorizzati. Componenti critici: Non si autorizza l'uso di questi prodotti come componenti critici all'interno di sistemi di controllo nucleari, sistemi necessari alla sopravvivenza o apparecchiature destinate all'impiego in ambienti pericolosi, senza l'esplicita approvazione scritta dell'Amministratore Delegato di TDK-Lambda EMEA.
Page 9
DPX Series Product HANDBOOK Un fusibile interno protegge l'unità e non deve essere sostituito dall'utente. Nell'eventualità di un difetto interno, restituire l'unità a TDK-Lambda UK LTD o a uno dei suoi agenti autorizzati SUPERFICIE CALDA Superfici esterne calde: Coerentemente con le norme locali in materia di salute & sicurezza professionali, i produttori sono tenuti a salvaguardare i tecnici di manutenzione, e inoltre gli utenti.
Page 10
ESPAÑOL LEA LAS INSTRUCCIONES DE SEGURIDAD Servicio: Estos productos no pueden ser reparados por los clientes. TDK-Lambda UK LTD. y sus agentes autorizados son los únicos que pueden llevar a cabo las reparaciones. Componentes fundamentales: Estos productos no pueden ser utilizados como componentes fundamentales en sistemas de control nuclear, sistemas de soporte vital o equipos a utilizar en entornos peligrosos sin el consentimiento expreso por escrito del Director General de TDK-Lambda EMEA.
Page 11
Product HANDBOOK Un fusible interno protege la unidad y este no debe ser nunca reemplazado por el usuario. En caso de existir algún defecto interno, la unidad debe ser enviada a TDK-Lambda UK LTD o a uno de sus agentes autorizados.
Page 12
Existe um fusível interno que protege a unidade e que não deve ser substituído pelo utilizador. Em caso de defeito interno, a unidade deve ser devolvida à TDK-Lambda UK LTD ou a um dos seus agentes autorizados. Page 11 of 18...
Page 13
DPX Series Product HANDBOOK SUPERFÍCIE QUENTE Superfícies quentes externas: Segundo com os regulamentos locais sobre saúde e segurança no local de trabalho, os fabricantes têm a obrigação de proteger os técnicos de manutenção, bem como os utilizadores. De forma a respeitar este regulamento, estes produtos deverão ter uma etiqueta que seja facilmente visível ao pessoal de assistência que aceda ao equipamento em geral, e que alerte, de forma legível, para o facto de as superfícies destes produtos poderem estar quentes, não devendo ser tocadas quando os produtos estão em funcionamento.
Page 14
DPX Series Product HANDBOOK General Safety Instructions: A suitable mechanical and fire enclosure must be provided by the end use equipment for mechanical and fire hazard protection. Environmental Specifications: Description Operation Storage Indoor Temperature See product data below See product data below Humidity 5 to 95% RH, non-condensing 5 to 95% RH, non-...
Page 15
DPX Series Product HANDBOOK Nomenclature: [ DPX models as described below: Unit Configuration Code: DPXa-bcde-f Where: = Power rating (15, 20, 30,40 or 60). = Nominal input voltage (12, 24 or 48) = Input range, 2:1 omit designation: (for 12V nom: 9-18Vdc, for 24V nom: 18-36Vdc and for 48V nom: 36-75Vdc).
Page 16
DPX Series Product HANDBOOK Output Parameters: DPX models Output designation Vout S3P3 3.3Vdc 3.9Vdc S5P1 5.1Vdc 6.2Vdc 5Vdc 6.2Vdc 12Vdc 15Vdc 15Vdc 18Vdc ±5Vdc ±6.2Vdc ±12Vdc ±15Vdc ±15Vdc ±18Vdc Not all outputs are available in all power ranges. For additional output parameters see specific product datasheet The output can be increased by turning the front panel potentiometer clockwise, turning the potentiometer counter clockwise will decrease the output.
Page 17
DPX Series Product HANDBOOK Cooling for unit The unit must be mounted on a DIN rail and must not be inverted, the output connection uppermost. Installation orientation: The ventilation openings on these products must not be impeded. Ensure that there is at least 50mm spacing between any obstruction and the ventilation openings.
Page 18
Common (0V) - Auxiliary No Connection + Output + Output (Main) (Main) TDK-Lambda UK Ltd Kingsley Avenue, Ilfracombe Devon, EX34 8ES Telephone - Sales and Service +44 (0)1271 856666 Head Office and Works +44 (0)1271 856600 Facsimile +44 (0)1271 864894 WEBSITE: www.uk.tdk-lambda.com...
Page 19
DPX Series Product HANDBOOK Page 18 of 18 DPX Series, 17185 issue 02, April 2013...
