Directed Electronics XPRESSKIT DLPKGM Mode D'emploi

1
Make the connections of the DLPKGM to the
vehicle:
1.A
Connector 1 (Black):
Determine the type of installation:
INSTALLATION WITH D2D
INSTALLATION WITHOUT D2D
Connector 2 (White):
1.B
Make the connections
Press and hold the programming
2
button. Plug in the connector 1
in the DLPKGM interface.
The LED will turn on, indicating
3
the beginning of programming.
Plug the connector 2 into the
DLPKGM interface.
4
WARNING: Connector 2 can be easily
plugged in backwards.
To enable the D2D communication between the
5
DLPKGM and the remote starter, press LOCK button.
While holding the programming
6
button, turn the key to the ignition
position.
7
The LED will flash rapidly.
8
Release the programming button.
9 Start the vehicle with the key.
10
The LED will turn off.
11
Turn the key OFF.
The interface is programmed.
CHEVROLET Silverado
FONCTIONNAL IF EQUIPPED
Bypass PK3, Passlock or VATS
Doorlock Control
Factory Alarm Control (OEM)
Trunk Release
Door status
WITH D2D
WITHOUT D2D
Connect wire to Remote-Starter/Alarm
Copyright © 2009, DIRECTED ELECTRONICS INC
2003-2007
you check for firmware and/or install guide
updates prior to installation of this product.
Heated Seats and Heated
Mirrors (Heated seats will turn
ON (low power) ONLY if the
engine temp is below 0°C
(32°F) when remote started.)
N.C. Lt.Green
N.C. Blue
Ignition
Pink
2
N.C.
Blue/White
Door trigger
Green
~
Data OBD2
Purple
PIN 2
N.C. Pink/White
2
1 2 4 8
3 5 6 7
WARNING: Connector 2 can be easily
9 10 11 12 13 14 15 16
plugged in backwards.
1
Lock
Lt.Green
Unlock Driver 1
Blue
Ignition
Pink
(-) While running (status) 2
Blue/White
Door trigger
Green
Data OBD2
Purple
N.C. Pink/White
PIN 2
2
1 2 4 8
3 5 6 7
9 10 11 12 13 14 15 16
Cut off one plug of the D2D connector, connect the blue*
wire to +12V and the black* wire to ground.
*Wire color may vary on the kit you have purchased.
Connect wire to vehicle
ALL RIGHTS RESERVED
DLPKGM
U p d at e A l e r t : F i r m w a r e
updates are posted to the web on
a regular basis. We recommend
WWW.XPRESSKIT.COM
Rear Defrost
Parking Light Control
Retained Accessory Power
Memory selection Driver 1 and
2 (by Unlock)
Red/White
N.C.
In D2D mode the analog Input
N.C.
Lt.Blue
(unlock, ground out) are disabled for
N.C.
White
N.C.
White/Black Starter or alarm
Tach
Violet/White
Tan/White N.C.
N.C.
Pink/Black
Red/White Trunk
Unlock Driver 2
Lt.Blue
Parking Light
White
White/Black N.C.
Tach
Violet/White
~
N.C.
Tan/White
N.C.
Pink/Black
WARNING: Connector 2 can be easily
plugged in backwards.
Blue* +12V
Black*
TECHNICAL
SUPPORT
INFORMATION
Rev.: 20091223
Start
Slidding doors
Tach
security.
OUTPUT INPUT
