Know Your Electric Pressure Washer
Read the owner's manual and safety instructions carefully before operating the Electric Pressure Washer. Compare the illustration
below to the unit in order to become familiar with the location of the various controls and adjustments. Save this manual for
future reference.
1
2
3
4
5
6
7
8
1. Handle
2. Trigger
3. Trigger gun
4. Storage bracket
5. Quick-Connect
nozzles (red 0°,
green 25°, gray 40°)
Technical Data
Rated Voltage ................................................... 120V AC | 60 Hz
Motor .................................................................................... 11A
Quick-Connect Tips ............................................... 0° | 25° | 40°
Foam Cannon Capacity ................................. 11.8 fl oz. (350 ml)
High-pressure Hose Length ..................................... 20 ft. (6 m)
Max Water Inlet Temperature ................................. 104ºF (40ºC)
Max Water Inlet Pressure ............................................... 100 PSI
11
14
15
6. Spray wand
7. Wheels
8. Quick-release collar
9. High-pressure hose
10. Hose holder
11. Needle clean-out tool
9
10
12
13
12. On/Off switch
13. Power cord with GFCI
14. Release switch
15. Water outlet/
high-pressure hose
connection
16. Safety lock
Max Pressure at initial discharge ................................. 1900 PSI
per CSA internal pressure testing
Rated Pressure under typical load ............................... 1300 PSI
Max Flow with nozzle open .........................1.5 GPM (5.7 L/min)
at minimum pressure
Rated Flow under typical load ....................1.2 GPM (4.5 L/min)
Power Cord Length .............................................. 35 ft. (10.7 m)
Net Weight ............................................................ 17.6 lbs (8 kg)
5
16
17
18
19
20
21
22
17. High-pressure
hose connection
18. Release button
19. Spray nozzle
20. Foam cannon holder
21. Foam cannon bottle
22. Water inlet + garden
hose adapter
