Sauder 412902 Instructions De Montage
  1. Manuels
  2. Marques
  3. Sauder Manuels
  4. Ameublement d'intérieur
  5. 412902
  6. Instructions de montage
Sauder 412902 Instructions De Montage

Sauder 412902 Instructions De Montage

Masquer les pouces

Publicité

Liens rapides

Télécharger ce manuel
CONTACT US FIRST
CONTACT US FIRST
sauder.com
sauder.com
sauder.com
BEFORE MAKING ANY RETURNS TO THE STORE.
BEFORE MAKING ANY RETURNS TO THE RETAILER.
sauder.com/service
Visit
Prefer the phone? Call or Text
Customer Service is available Monday-Friday - 8:30 a.m. to 5:00 p.m. ET (except holidays)
Executive Desk
Palladia Collection | Model 412902
Scan to rate and review
your piece at Sauder.com
Your opinion matters!
to order replacement parts, view video assembly tips, or chat with a live rep.
800.445.1527
.
Business or pleasure.
Works both ways.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-48
Français pg 49-54
Español pg 55-60
Lot # 598390
Purchased: __________________
09/05/23

Publicité

loading

Manuels Connexes pour Sauder 412902

Sommaire des Matières pour Sauder 412902

  • Page 1 Business or pleasure. Works both ways. Executive Desk NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Palladia Collection | Model 412902 PLEASE READ AND KEEP FOR FUTURE REFERENCE. English pg 1-48 Français pg 49-54 Scan to rate and review Español pg 55-60 your piece at Sauder.com...
  • Page 2 RIGHT DRAWER FRONT (1) LEFT KEYBOARD DRAWER SIDE (1) RIGHT END (1) LEFT DRAWER SIDE (2) RIGHT KEYBOARD DRAWER SIDE (1) BOTTOM (2) RIGHT DRAWER SIDE (2) KEYBOARD DRAWER BACK (1) MM KEYBOARD DRAWER BOTTOM (1) Page 2 www.sauder.com/service 412902...
  • Page 3 While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identification to help identify similar parts. 412902 www.sauder.com/service...
  • Page 4 LARGE BUMPER H10 HINGE - 2 K38 KNOB - 8 KEYBOARD HINGE - 2 CARD - 1 GROMMET DRAWER P79 GROMMET - 3 M40 BUMPER CARD - 1 WITH CAP - 2 APPLIQUE CARD - 4 Page 4 www.sauder.com/service 412902...
  • Page 5 1/2" PAN HEAD SCREW - 44 S116 SMALL 1/2" PAN HEAD SCREW - 12 9/16" LARGE HEAD SCREW - 2 S117 S124 9/16" TAPERED HEAD SCREW - 8 1-1/8" MACHINE SCREW - 4 S125 9/16" MACHINE SCREW - 4 412902 www.sauder.com/service Page 5...
  • Page 6 The arrow in the HIDDEN CAM must point Arrow toward the hole in the edge of the board. Hidden Cam Hole Insert the CAM SCREW or CAM DOWEL into the HIDDEN CAM. Tighten the HIDDEN CAM. Page 6 www.sauder.com/service 412902...
  • Page 7 Step 1 Look for this icon. It means a video assembly tip is available at www.sauder.com/service/tips Find the numbered video or scan the QR code. å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
  • Page 8 NOTE: The EXTENSION SLIDES will be used later for the KEYBOARD DRAWER. 40BC 40BA Push the black lever and pull the SLIDE from the RAIL. SMALL 1/2" PAN HEAD SCREW (3 used in this step) 40BA Open end Page 8 www.sauder.com/service 412902...
  • Page 9 Fasten the RIGHT UPRIGHT (J) and the RIGHT END (L) to the BOTTOM (M). Tighten four HIDDEN CAMS. Just think. The sooner you do this, the sooner you do something else. Edge without holes Edge without holes Large hole must be here 412902 www.sauder.com/service Page 9...
  • Page 10 RIGHT END (L). Use four 1/2" PAN HEAD SCREWS (S15) through the METAL BRACKETS on the RIGHT UPRIGHT and RIGHT END and into the holes in the RIGHT BACK. 1/2" PAN HEAD SCREW (4 used in this step) Page 10 www.sauder.com/service 412902...
  • Page 11 Push three HIDDEN CAMS (F9) into the TOP MOLDING (C). å Fasten two LONG METAL BRACKETS (G17) to the TOP MOLDING (C). Use two 1/2" PAN HEAD SCREWS (S15). 1/2" PAN HEAD SCREW (2 used in this step) Arrow 412902 www.sauder.com/service Page 11...
  • Page 12 Step 6 å Turn seventeen CAM SCREWS (F16) into the TOP (A). Page 12 www.sauder.com/service 412902...
  • Page 13 Step 7 å Fasten the TOP MOLDING (C) to the TOP (A). Tighten three HIDDEN CAMS. Surface with HIDDEN CAMS 412902 www.sauder.com/service Page 13...
  • Page 14 Insert two WOOD DOWELS (F19) into the TOP (A). å Fasten the RIGHT UPRIGHT (J) and RIGHT END (L) to the TOP (A). Tighten six HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the TOP insert into the RIGHT END. Page 14 www.sauder.com/service 412902...
  • Page 15 Step 9 å Push two HIDDEN CAMS (F9) into the MODESTY PANEL (H). Arrow 412902 www.sauder.com/service Page 15...
  • Page 16 Fasten the MOLDING (GG) to the MODESTY PANEL (H). Use three 1-1/2" FLAT HEAD SCREWS (S9). å NOTE: You should start each SCREW a few turns before completely tightening any of them. Flat edge 1-1/2" FLAT HEAD SCREW (3 used in this step) Page 16 www.sauder.com/service 412902...
  • Page 17 Insert one GROMMET (P79) into the large hole in the BOTTOM (M). D E N H I D i t h f a c S u r 1-1/2" FLAT HEAD SCREW (2 used in this step) 412902 www.sauder.com/service Page 17...
  • Page 18 LEFT UPRIGHT (G), and remaining BOTTOM (M). å Turn four CAM SCREWS (F16) into the LEFT END (E) and LEFT UPRIGHT (G). å Insert one GROMMET (P79) into the large hole in the LEFT UPRIGHT (G). Arrow Arrow Page 18 www.sauder.com/service 412902...
  • Page 19 EXTENSION RAIL in to find the other holes that line up with the holes in the LEFT UPRIGHT. Turn a SCREW into these holes. SMALL 1/2" PAN HEAD SCREW (3 used in this step) 40BA Open end 412902 www.sauder.com/service Page 19...
  • Page 20 Step 14 å Fasten two HINGE BRACKETS (H6) to the LEFT END (E). Use the SCREWS in the HINGE BRACKETS. å NOTE: You should start each SCREW a few turns before completely tightening any of them. Page 20 www.sauder.com/service 412902...
  • Page 21 Fasten the LEFT END (E) and LEFT UPRIGHT (G) to the LEFT BACK (F) and BOTTOM (M). Tighten four HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the LEFT END and LEFT UPRIGHT insert into the LEFT BACK. The large hole must be here. 412902 www.sauder.com/service Page 21...
  • Page 22 Insert two WOOD DOWELS (F19) into the TOP (A). å Fasten the LEFT END (E) and the LEFT UPRIGHT (G) to the TOP (A). Tighten six HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the TOP insert into the LEFT END. Page 22 www.sauder.com/service 412902...
  • Page 23 å Fasten the LEFT UPRIGHT (G) to the MODESTY PANEL (H). Use two 1-1/2" FLAT HEAD SCREWS (S9). 1-1/2" FLAT HEAD SCREW (2 used in this step) 1/2" PAN HEAD SCREW (2 used in this step) 412902 www.sauder.com/service Page 23...
  • Page 24 Fasten sixteen METAL BRACKETS (G16) to the SKIRTS (N and O). Use sixteen 1/2" PAN HEAD SCREWS (S15). å NOTE: Be sure the edges of the METAL BRACKETS are even with the edges of the SKIRTS. 1/2" PAN HEAD SCREW (16 used in this step) Page 24 www.sauder.com/service 412902...
  • Page 25 BOTTOMS (M). Use sixteen 1/2" PAN HEAD SCREWS (S15) through the METAL BRACKETS on the SKIRTS and into the holes in the ENDS, UPRIGHTS, and BOTTOMS. 1/2" PAN HEAD SCREW (16 used in this step) 412902 www.sauder.com/service Page 25...
  • Page 26 SHELF PINS into the hole locations of your choice in the LEFT your arms. END (E) and LEFT UPRIGHT (G). Set the ADJUSTABLE SHELF (D) onto the SHELF PINS. å Insert one GROMMET (P79) into the large hole in the BOTTOM (M). (4 used) Page 26 www.sauder.com/service 412902...
  • Page 27 Fasten two HINGES (H10) to the DOOR (B). Use four 9/16" TAPERED HEAD SCREWS (S117). å NOTE: You should start each SCREW a few turns before completely tightening any of them. S117 9/16" TAPERED HEAD SCREW (4 used in this step) 412902 www.sauder.com/service Page 27...
  • Page 28 Peel BUMPERS from one BUMPER CARD (M40) and stick them onto the DOOR (B) as shown. The screw on the back side of the HINGE will fit into this slot. This screw will fit into this slot. Then tighten the screw. Page 28 www.sauder.com/service 412902...
  • Page 29 To adjust the DOOR in or out (depth), loosen the mounting screw one turn and move the DOOR in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) 412902 www.sauder.com/service Page 29...
  • Page 30 Fasten the KEYBOARD DRAWER SIDES (JJ and KK) to the KEYBOARD DRAWER BACK (LL). Use two 1-1/2" FLAT HEAD SCREWS (S9). Edge with holes Edge with holes Edge with holes 1-1/2" FLAT HEAD SCREW (2 used in this step) Page 30 www.sauder.com/service 412902...
  • Page 31 KEYBOARD DRAWER SIDES (JJ and KK) and KEYBOARD DRAWER BACK (LL). Use six 1-1/2" FLAT HEAD SCREWS (S9). å NOTE: You should start each SCREW a few turns before completely tightening any of them. 1-1/2" FLAT HEAD SCREW (6 used in this step) 412902 www.sauder.com/service Page 31...
  • Page 32 SIDES (JJ and KK). Use six SMALL 1/2" PAN HEAD SCREWS (S40) starting with the hole shown in the enlarged diagram. Open end 40BC 40BC Open end SMALL 1/2" PAN HEAD SCREW (6 used in this step) Page 32 www.sauder.com/service 412902...
  • Page 33 Fasten two KNOBS (K38) to the KEYBOARD DRAWER FRONT (HH). Use two 1-1/8" MACHINE SCREWS (S124). S117 9/16" TAPERED HEAD SCREW (4 used for the KEYBOARD HINGES) S124 1-1/8" MACHINE SCREW (2 used for the KNOBS) 412902 www.sauder.com/service Page 33...
  • Page 34 NOTE: You should start each SCREW a few turns before completely tightening any of them. å Peel two BUMPERS from the LARGE BUMPER CARD (M38) and stick them onto the KEYBOARD DRAWER SIDES (JJ and KK) as shown. S116 9/16" LARGE HEAD SCREW (2 used in this step) Page 34 www.sauder.com/service 412902...
  • Page 35 Step 29 å Push eight SMALL HIDDEN CAMS (F17) into the SMALL DRAWER SIDES (R and S). Arrow 412902 www.sauder.com/service Page 35...
  • Page 36 Step 30 å Turn eight STRAIGHT HEAD CAM SCREWS (F18) into the SMALL DRAWER FRONTS (P and Q). Page 36 www.sauder.com/service 412902...
  • Page 37 Fasten a SMALL DRAWER BACK (T) to the SMALL DRAWER SIDES (R and S). Use four 1-1/2" FLAT HEAD SCREWS (S9). å NOTE: Be sure the DRAWER BOTTOM (U) inserts into the groove of the SMALL DRAWER BACK (T). å Repeat this step using the SMALL RIGHT DRAWER FRONT (Q). 412902 www.sauder.com/service Page 37...
  • Page 38 Peel DRAWER APPLIQUES from one DRAWER APPLIQUE CARD (P57) and stick them onto each visible HIDDEN CAM. å Repeat this step for the remaining SMALL DRAWER. S124 1-1/8" MACHINE SCREW (2 used in this step) (2 used) Page 38 www.sauder.com/service 412902...
  • Page 39 Step 33 å Push eight SMALL HIDDEN CAMS (F17) into the DRAWER SIDES (X and Y). Arrow 412902 www.sauder.com/service Page 39...
  • Page 40 Step 34 å Turn eight STRAIGHT HEAD CAM SCREWS (F18) into the DRAWER FRONTS (V and W). Page 40 www.sauder.com/service 412902...
  • Page 41 Fasten the DRAWER BACK (Z) to the DRAWER SIDES (X and Y). Use four 1-1/2" FLAT HEAD SCREWS (S9). å NOTE: Be sure the DRAWER BOTTOM (U) inserts into the groove of the DRAWER BACK (Z). å Repeat this step using the RIGHT DRAWER FRONT (W). 412902 www.sauder.com/service Page 41...
  • Page 42 Peel DRAWER APPLIQUES from one DRAWER APPLIQUE CARD (P57) and stick them onto each visible HIDDEN CAM. å Repeat this step for the remaining DRAWER. S125 9/16" MACHINE SCREW (2 used in this step) (2 used) Page 42 www.sauder.com/service 412902...
  • Page 43 Step 37 å Push eight SMALL HIDDEN CAMS (F17) into the LARGE DRAWER SIDES (CC and DD). Arrow 412902 www.sauder.com/service Page 43...
  • Page 44 Step 38 å Turn eight STRAIGHT HEAD CAM SCREWS (F18) into the LARGE DRAWER FRONTS (AA and BB). Page 44 www.sauder.com/service 412902...
  • Page 45 Fasten the LARGE DRAWER BACK (EE) to the LARGE DRAWER SIDES (CC and DD). Use four 1-1/2" FLAT HEAD SCREWS (S9). å NOTE: Be sure the LARGE DRAWER BOTTOM (FF) inserts into the groove of the LARGE DRAWER BACK (EE). å Repeat this step for the LARGE RIGHT DRAWER FRONT (BB). 412902 www.sauder.com/service Page 45...
  • Page 46 Peel DRAWER APPLIQUES from one DRAWER APPLIQUE CARD (P57) leave without a bite. and stick them onto each visible HIDDEN CAM. å Repeat this step for the remaining LARGE DRAWER. S125 9/16" MACHINE SCREW (2 used in this step) (2 used) Page 46 www.sauder.com/service 412902...
  • Page 47 Slide another FILE GLIDE (B11) onto the other end of the FILE RODS (B16), then press this FILE GLIDE over the LARGE LEFT DRAWER SIDE (CC). å Repeat this step for the remaining LARGE DRAWER. t e r L e t 412902 www.sauder.com/service Page 47...
  • Page 48 . 1 5 l l b s . l b s . b s . 1 5 l l b s . Scan to rate and review your piece at Sauder.com Your opinion matters! Page 48 www.sauder.com/service 412902...
  • Page 49 Modèle 412902 Bureau exécutif Utilisez les instructions d’ a ssemblage en français avec les NOUS CONTACTER EN PREMIER schémas étape par étape du manuel d’instruction en anglais. AVANT D'EFFECTUER TOUT RETOUR AU MAGASIN. Chaque étape en français correspond à la même étape en Nous faisons de notre mieux pour nous assurer que votre meuble anglais.
  • Page 50 MONTANT DROIT. Faire tourner une VIS dans ces trous. REMARQUE : Les COULISSES D'EXTENSION seront utilisées ultérieurement pour le TIROIR DE CLAVIER. ÉTAPE 3 Fixer le MONTANT DROIT (J) et l'EXTRÉMITÉ DROITE (L) au DESSOUS (M). Serrer quatre EXCENTRIQUES ESCAMOTABLES. Page 50 www.sauder.com/service 412902...
  • Page 51 VIS dans le trou indiqué dans le schéma agrandi. Ensuite, enfiler la cartouche interne de la GLISSIÈRE D'EXTENSION vers l'intérieur pour trouver les autres trous qui sont alignés sur les trous dans le MONTANT GAUCHE. Faire tourner une VIS dans ces trous. 412902 www.sauder.com/service Page 51...
  • Page 52 CHARNIÈRES aux SUPPORTS DE CHARNIÈRE et garder la PORTE dans une position verticale en tout temps. Séparer les TAMPONS d’une FICHE AVEC TAMPONS (M40) et les coller sur la PORTE (B) comme l'indique le schéma. Page 52 www.sauder.com/service 412902...
  • Page 53 TIROIR (R et S). Utiliser quatre VIS TÊTE PLATE 38 mm (S9). REMARQUE : S'assurer que le FOND DE TIROIR (U) s'encastre dans la rainure de l'ARRIÈRE DE PETIT TIROIR (T). Répéter cette étape pour le DEVANT DROIT DE PETIT TIROIR (Q). 412902 www.sauder.com/service Page 53...
  • Page 54 Décoller les APPLIQUÉS des FICHES D'APPLIQUÉS (P80) et coller les sur chaque EXCENTRIQUE ESCAMOTABLE visible. REMARQUE : Prière de lire les informations importantes sur la sécurité figurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. Page 54 www.sauder.com/service 412902...
  • Page 55 Si POR SEPARADO) PUERTA ................1 necesita ponerse en MOLDURA DE PANEL SUPERIOR ....1 40BA RIEL DE EXTENSIÓN ............2 contacto con Sauder en ESTANTE AJUSTABLE ..........1 40BC CORREDERA DE EXTENSIÓN ........2 cuanto a esta unidad, EXTREMO IZQUIERDO ..........1 CORRIMIENTO DE ARCHIVERO.....4 refiérase al número...
  • Page 56 PARAL DERECHO. Atornille un TORNILLO dentro de estos agujeros. NOTA: Las CORREDERAS DE EXTENSIÓN se utilizarán más tarde para el CAJÓN DE TECLADO. PASO 3 Fije el PARAL DERECHO (J) y el EXTREMO DERECHO (L) al FONDO (M). Apriete cuatro EXCÉNTRICOS ESCONDIDOS. Page 56 www.sauder.com/service 412902...
  • Page 57 TORNILLOS DE CABEZA PLANA de 38 mm (S9). continuación, deslice el cartucho interno del RIEL DE EXTENSIÓN hacia el interior para encontrar los otros agujeros que se alinean con los agujeros del PARAL IZQUIERDO. Atornille un TORNILLO dentro de estos agujeros. 412902 www.sauder.com/service Page 57...
  • Page 58 BISAGRAS a las MÉNSULAS DE BISAGRA manteniendo la PUERTA en una posición vertical en todo momento. Separe los TOPES de una TARJETA CON TOPES (M40) y aplique los sobre la PUERTA (B) como se muestra. Page 58 www.sauder.com/service 412902...
  • Page 59 PLANA de 38 mm (S9). NOTA: Asegúrese de que el FONDO DE CAJÓN (U) ajuste dentro de la ranura del DORSO DE CAJÓN PEQUEÑO (T). Repita este paso para la CARA DERECHA DE CAJÓN PEQUEÑO (Q). 412902 www.sauder.com/service Page 59...
  • Page 60 APLICACIONES (P80) y aplique las sobre cada EXCÉNTRICO ESCONDIDO visible. NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpiar con un trapo húmedo. Seque con un paño. Page 60 www.sauder.com/service 412902...
  • Page 61 à Les téléviseurs peuvent être particulièrement un téléviseur. cet effet. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. 412902 www.sauder.com/service Page 61...
  • Page 62 Además, el peso soportar un televisor. diseñadas para soportar un televisor. y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 62 www.sauder.com/service 412902...
  • Page 63 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 64 CONTACT US FIRST BEFORE MAKING ANY RETURNS TO THE RETAILER. Dear Valued Customer: Register and review Thanks so much for choosing Sauder® furniture. I hope the your new product purchase and assembly process was a positive experience at Sauder.com and you feel good about the furniture you just built.
