7064348COM
Nesting Tables Reclaimed Oak
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
B347064348COM00 SF
Tough
Publicité
Manuels Connexes pour Queer Eye 7064348COM
Sommaire des Matières pour Queer Eye 7064348COM
- Page 1 7064348COM Nesting Tables Reclaimed Oak B347064348COM00 SF Date of Purchase ___ / ___ / ___ Lot Number: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Do Not Return This Product! Contact our customer service team for help first.
- Page 2 Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Visit ameriwoodhome.com Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 0.5-1 HOUR - Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Page 3 Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.
- Page 4 Board Identification Not actual size Top frame Side fframe T7064348010SF T7064348020SF QTY: 2 PCS Fixed panel Top frame T7064348030SF T7064348040SF Foot Foot T7064348050SF T7064348060SF QTY: 2 PCS QTY: 2 PCS ameriwoodhome.com...
- Page 5 Board Identification Not actual size ameriwoodhome.com...
- Page 6 Hardware Bag Reference Number: 27064348COM0 Part List Actual Size Ø3.5X12mm Ø8X30mm Ø1/4X28mm Ø1/4X35mm Screw Wood dowel Bolt Bolt TSF0801 TSF0501 TSF1605 TSF1602 Not Actual Size Ø7X13XT1.5mm M4X54mm Ø7 X10XT1.5mm x 10 x 10 Spring washer Washer Wall Bracket Hex key TSF0009 TSF2403 TSF2633...
- Page 7 STEP Ø8X30mm Ø7X13XT1.5mm M4X54mm Ø7 X10XT1.5mm Ø1/4X28mm 1.1 Attach (1) to (B)x2 as below illustrated. 1.2 Attach (B)x2 to (A) with (2), (5), (6) as below illustrated. Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole. ameriwoodhome.com...
- Page 8 STEP Ø7X13XT1.5mm M4X54mm Ø7 X10XT1.5mm Ø1/4X35mm 2.1 Attach (E), (F) to (C) with (4), (5), (6) as below illustrated. ameriwoodhome.com...
- Page 9 STEP Ø3.5X12mm 3.1 Attach (7) to (D) with (3) as below illustrated. 3.2 Attach (D) to (E), (F) with (3) as below illustrated. ameriwoodhome.com...
- Page 10 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is not approved for use with a television.
- Page 11 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community * Exclusive deals and discount codes * Quick and easy replacement part service To register your product, visit ameriwoodhome.com Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You"...
- Page 12 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 13 Español Identificación de los Paneles Lista de Piezas (Página 6) Este no es el tamaño real (Página 4, 5) Tamaño real Este no es el tamaño real (5) Arandela elástica Taco de madera (6) Arandela MARCO SUPERIOR Perno (7) Soporte de pared Tornillo MARCO LATERAL (8) Llave hexagonal...
- Page 14 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: (sans frais) du Lundi au Vendredi de 9h à...
- Page 15 Français Liste des pièces (Page 6) Identification des matériaux Pas de taille réelle (Page 4, 5) Taille réelle Pas de taille réelle Cheville en bois (5) Rondelle élastique (6) Rondelle Boulon CADRE SUPÉRIEUR (7) Support mural CADRE LATÉRAL Boulon (8) Clé hexagonale CADRE SUPÉRIEUR PANNEAU FIXE PIED...
