Pre-Installation

PLANNING INSTALLATION

Read through all the instructions before begining assembly. Unpack and identify all the parts. Place them on a at, non-abrasive surface.
Assembly by two people is recommended.
TOOLS REQUIRED (NOT INCLUDED)
1/4 in. Hex wrench

HARDWARE INCLUDED

NOTE: Hardware not shown to actual size.
NO. Description
AA
1/4 * 5/8 in. bolt
BB
1/4 * 2-1/2 in. bolt
CC
5/16 * 1-1/2 in. bolt
DD
1/4 in. metal washer
5/16 in. metal washer
EE
FF 1/4 in. nut
GG 5/16 in. lock washer
5 /16 in. Hex wrench
Quantity
1 spare
4
4
8
4
4
4
3
Part
Please contact 1-855-HD-HAMPTON for further assistance.
HOMEDEPOT.CA
