LEDVANCE CUT OFF WALL PACK
Installation Instructions
PERFORMANCE CLASS
OPTI-SELECT CUT OFF WALL PACK
The Performance Class OPTI-SELECT CUT OFF Wall Pack
offers three lumen packages, three CCTs and 3 light
distributions in the same product, while being full cut off to help
reduce light pollution and support dark sky initiatives . It's
controls-ready with a 3-pin sensor receptacle and features an
integrated photocell for energy-efficient dusk-to-dawn
operation. With a sleek, durable design, this wall pack merges
aesthetic appeal with long-lasting performance to support
efficient lighting practices
For warranty coverage, please register at www.ledvanceUS.com
Please Read All Instructions Before Attempting Installation
• TO PREVENT PERSONAL INJURY OR PRODUCT DAMAGE, ONLY LICENSED ELECTRICIANS SHOULD PERFORM ALL
INSTALLATION SERVICES.
• TO AVOID ELECTRIC SHOCK OR COMPONENT DAMAGE, DISCONNECT POWER BEFORE ATTEMPTING INSTALLATION OR
SERVICING.
• THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE (NEC) AND ALL APPLICABLE
FEDERAL, STATE AND LOCAL ELECTRIC CODES AND SAFETY STANDARDS.
• USE ONLY UL (OR OTHER NTRL) APPROVED WIRE FOR INPUT/OUTPUT CONNECTIONS. MINIMUM SIZE 18 AWG OR 14 AWG
FOR CONTINUOUS RUNS.
• DO NOT INSTALL IN A HAZARDOUS ATMOSPHERE, EXCEPT WHERE THE AMBIENT TEMPERATURE DOES NOT EXCEED THE
RATED OPERATING TEMPERATURE OF THE FIXTURE.
• USE CAUTION WHEN HANDLING THIS PRODUCT DURING OR AFTER OPERATION AS IT MAY BECOME HOT AND CAUSE
BURNS. DISCONNECT PRODUCT AND ALLOW COOLING PRIOR TO SERVICING.
• ANY ALTERATION OR MODIFICATION OF THIS PRODUCT IS EXPRESSLY FORBIDDEN AS IT MAY CAUSE SERIOUS
PERSONAL INJURY, DEATH, PROPERTY DAMAGE AND/OR PRODUCT MALFUNCTION.
• TO PREVENT PRODUCT MALFUNCTION AND / OR ELECTRICAL SHOCK THIS PRODUCT MUST BE PROPERLY GROUNDED.
• CAUTION - RISK OF FIRE
• THIS LUMINAIRE IS DESIGNED TO OPERATE IN AMBIENT TEMPERATURES RANGING FROM -40°F TO +122°F
(-40°C TO +50°C) AND IS RATED FOR WET LOCATIONS.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:(1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation. Please visit: https://www.ledvanceus.com/fccpart15b
4308683
WARNING
Table des Matières
loading

Manuels Connexes pour Ledvance CUT OFF WALL PACK

Sommaire des Matières pour Ledvance CUT OFF WALL PACK

  • Page 1 Installation Instructions PERFORMANCE CLASS OPTI-SELECT CUT OFF WALL PACK The Performance Class OPTI-SELECT CUT OFF Wall Pack offers three lumen packages, three CCTs and 3 light distributions in the same product, while being full cut off to help reduce light pollution and support dark sky initiatives . It’s...

  • Page 2: Safety Precautions

    4262082 Safety Precautions: IMPORTANT: READ CAREFULLY BEFORE INSTALLING THE FIXTURE. RETAIN FOR FUTURE REFERENCE. GENERAL: Upon receipt of the fixture, thoroughly inspect for any freight damage which should be brought to the attention of the delivery carrier. Trouble Shooting Checklist Check your power source.

  • Page 3: Installation Instructions

    4262082 Installation Instructions 1. Use a Hex Wrench to loosen the screws and 2. Install the mounting bracket onto the junction box. remove the mounting bracket from the fixture. 3. Secure the safety cable to the bracket to hold the 4.

  • Page 4: Wiring Diagram

    4262082 5. Install the fixture onto the mounting bracket.. 6. Tighten the fixture securely using the Allen Wrench. Wiring Diagram: 4308683...

  • Page 5: Applique Murale À Défilement Ledvance

    4262082 APPLIQUE MURALE À DÉFILEMENT LEDVANCE Directives d’installation APPLIQUE MURALE À DÉFILEMENT OPTI-SELECT DE CLASSE PERFORMANCE L’applique murale OPTI-SELECT À DÉFILEMENT offre trois plages de lumens, trois TCP et 3 distributions d’éclairage dans un même produit tout en procurant un défilement total pour réduire la pollution lumineuse et répondre aux exigences des normes pour la protection...

  • Page 6: Avertissements De Sécurité

    4262082 Avertissements de sécurité : IMPORTANT : Veuillez lire attentivement les directives d’installation avant l’installation de ce luminaire. Garder ces directives pour référence future. GÉNÉRAL : Lors de la réception de l'appareil, vérifiez soigneusement qu'il n'y a pas de dommages causés durant le transport et si des dommages sont constatés aviser le transporteur.
  • Page 7 4262082 Directives d’installation 1. À l’aide d’une clé hexagonale, desserrer les vis et 2. Installer le support de montage sur la boîte de jonction. retirer le support du montage du luminaire. Alimentation Noir Blanc Neutre Vert Mise à la terre M.-À-T.

  • Page 8: Dessin De Câblage

    4262082 5. Installer le luminaire sur le support de montage. 6. Resserrer le luminaire de manière sécuritaire à l’aide d’une clé hexagonale. Dessin de câblage : 4308683...
