INSTALLATION AND
ADJUSTMENT MANUAL
16-001-xC EVER 65 Mobile Clean
M000345
16-001-xC EVER 65 Mobile Clean
16-001-xS EVER 65 Mobile Soft
DE Handbuch für Installation und Anpassung
IT Manuale per l'installazione e la regolazione
ES Manual de instalación y ajuste
FI Asennus- ja säätöohje
FR Manuel d'installation et de réglage
NL Handboek voor installatie en instellingen
PL
RUS
ARB
SE Monterings- och justeringsmanual
GR
16-001-xS EVER 65 Mobile Soft
Publicité
Manuels Connexes pour SMS EVER 65 Mobile Clean
Sommaire des Matières pour SMS EVER 65 Mobile Clean
- Page 1 INSTALLATION AND ADJUSTMENT MANUAL 16-001-xS EVER 65 Mobile Soft 16-001-xC EVER 65 Mobile Clean M000345 16-001-xC EVER 65 Mobile Clean 16-001-xS EVER 65 Mobile Soft DE Handbuch für Installation und Anpassung IT Manuale per l'installazione e la regolazione ES Manual de instalación y ajuste FI Asennus- ja säätöohje...
- Page 2 Un montaggio corretto è della massima importanza e non è responsabilità di SMS Smart Media Solutions Solutions AB. Faulty mounting may result in injury to persons or damage to equipment. SMS will not be AB. Un montaggio erroneo può avere come conseguenza danni a persone o cose. SMS declina ogni responsible in any way if the product has been mounted incorrectly.
- Page 3 Nei casi in cui si faccia riferimento alla garanzia, si deve inviare a SMS il prodotto insieme alla purchase receipt are to be returned to SMS. The name of the supplier and the date of purchase must ricevuta d’acquisto in originale. Sulla ricevuta devono essere chiaramente leggibili nome del be clearly legible on the receipt.
- Page 4 EVER 65 MOBILE ASSEMBLY INSTRUCTIONS YOU WILL NEED Allen key No. 4, 5 NOT INCLUDED Display NUMBER OF PERSONS REQUIRED...
- Page 5 EVER 65 MOBILE LIST OF PARTS (2x) (1x) EVER 65 Mobile EVER 65 Mobile Clean Soft (2x) (4x) (2x) (2x)
- Page 6 EVER 65 MOBILE LIST OF PARTS (continued) (1x) (1x) (2x) (4x) S1 (8x) SCREW KIT ISO 4762 [M6x10] SCREW KIT Screw M6x10 Screw M6x16 Screw M6x30 S2 (4x) Screw M8x20 ISO 7380 [M6x6] Screw M8x30 Screw M8x40 Washer 6,4 Multiple washer Plastic spacer 8,2/15x5 Plastic spacer 8,2/15x10...
- Page 7 EVER 65 MOBILE...
- Page 8 EVER 65 MOBILE FRONT FRONT SIDE REAR A2 (2x) A1 (2x) S1 (8x) (8x) Warning! Ensure the legs are S1 (8x) installed correctly to prevent risk of the stand tipping over...
- Page 9 EVER 65 MOBILE Arrow to point at leg...
- Page 10 EVER 65 MOBILE 310mm 310mm *Install handles after installing (optional) shelves...
- Page 11 EVER 65 MOBILE OPTIONAL: Adjust height Dismount bracket...
- Page 12 EVER 65 MOBILE OPTIONAL: Screen mounting height options: Adjust height Configuration Dimension (mm) number (from center of display) 1553 1503 1453 1403 1353 min.5mm *Refer dimension drawings (page 20)
- Page 13 EVER 65 MOBILE S2 (4x) (4x)
- Page 14 EVER 65 MOBILE Dismount back covers EVER 65 Mobile EVER 65 Mobile Clean Soft...
- Page 15 EVER 65 MOBILE Guide cable...
- Page 16 EVER 65 MOBILE Remount back covers EVER 65 Mobile EVER 65 Mobile Clean Soft...
- Page 17 EVER 65 MOBILE Prepare display brackets C1 (1x) C2 (1x) K1 (4x) SCREW KIT...
- Page 18 EVER 65 MOBILE Mount display Caution! Grooves in bracket for display shelf accessory only. Do not slot in display brackets.
- Page 19 EVER 65 MOBILE Secure! F1(4x) (4x)
- Page 20 27,80 129,4 min 200 - max 600 11,82 6,70 7,65 31,26 300,1 170,1 194,4 13,01 330,4 All dimensions in mm. Dimensions in brackets [ ] are in inches SMS Smart Media Solutions AB Högbergsgatan 26B 116, 20 Stockholm, Sweden www.smartmediasolutions.com...
