One-year standard tool warranty
Should your Tacwise air tool become defective due to faulty materials or workmanship within 12 months from the date of purchase, we guarantee to replace all
defective parts free of charge or at our discretion, replace the tool entirely. However, this one-year warranty does not cover any consumable parts such as
drivers, O-rings, springs etc.
6-month standard consumable parts warranty
Tacwise air tools are warranted to be free from defects with all its original consumable parts for 6-months from the date of purchase.
Neither of these warranties cover:
• Tools that have received unauthorised changes or additions.
• Defects caused by using accessories, components or spare parts other than approved/genuine Tacwise accessories or parts.
• Component parts that are subject to natural wear and tear caused by use in accordance with our operating instructions.
• Defects to the tool caused by improper use, abnormal environmental conditions or inappropriate operating conditions, non-compliance with our operating
instructions or insufficient servicing or maintenance.
• Proof of purchase must be produced with an original receipt.
Operating Instructions
Technical data
Characteristics
Model
Staple type
Staple length range
Magazine capacity
Minimum operating air pressure
Maximum operating air pressure
Air inlet
Air consumption
Weight
Vibration emission level*
* The declared vibration emission level represents the main applications of the tool. However if the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission may differ. This may significantly increase exposure level over the total working period.
CE – Declaration of Conformity
A8016V
Tacwise declares that this power tool has been designed in compliance with the Regulations and Standards of the European Directives.
Quality Department, Tacwise Group Plc – UK
Features (Fig. A)
1. Trigger
2. Quick-release plug (Euro fitting)
3. Magazine release lever
4. Magazine
Set up
Your air tool is fully assembled when you receive it. Before using it, attach the air line and desired air system accessories. See Fig. B for the recommended
accessories and connection order. Be sure the air hose is de-pressurised when installing or removing adaptors to the air line.
Connecting the tool to an air supply (Fig. B)
• Determine if the tool needs oil and, if necessary, place two drops of oil in the air plug as shown in Fig. B. If you are using an automatic in-line oiler, check and
add oil if necessary.
• Turn the compressor on and set the regulator to the proper pressure for the size and type of fastener being used.
• Connect the tool to the air supply.
Loading the fasteners (Fig. C)
• Hold the tool with the magazine at the top.
• Depress the magazine release lever to release the magazine.
• Pull the moveable magazine out.
• Place a strip of fasteners (with legs facing up) into the magazine channel.
• Slide the magazine shut and depress the magazine release lever to lock.
NOTE: We strongly recommend that you only use approved/genuine Tacwise staples.
Operating the tool
• Connect the tool to the air supply. Make sure the air pressure is in correct range denoted in section of Technical data.
• Load fasteners as directed in the section called Loading the fasteners.
• Hold the body of the tool and press the nose to the work surface, be sure the tool is straight and then gently depress the trigger to drive the fastener.
• Lift the tool off the work surface.
Removing a jammed fastener
NOTE: You must remove any jammed fasteners before using the tool any further. If you continue to try to fire a fastener while the tool is jammed, you could
cause damage to the mechanism.
• Disconnect the tool from the compressed air system.
• Remove any unused fasteners from the magazine channel; this should clear the jammed fastener(s).
• Following the removal of a jammed fastener, always carefully test the tool function before proceeding with any work. If fasteners become jammed frequently,
have the tool serviced by a Tacwise Engineer or appointed service agent.
FASTENING TOOLS FOR THE PROFESSIONAL
Value
A8016V
Tacwise 80 series staples
4mm (5/32") – 16mm (5/8")
150
60psi / 4.14 bar
100psi / 6.89 bar
1/4" NPT
0.6 CFM @ 90psi / 6.20 bar
0.9kg (2.0lbs)
1.7m/s
2
6
