SLIDING BAR
BARRE À GLISSIÈRE
9
9A
B
B
MEASURE AND DRILL
THROUGH UPPER
WALL
ON POINT "B"
MESURER ET PERCER
LA PARTIE SUPÉRI
EURE DU
MUR AU POINT
DE PERÇAGE "B"
SCREW
THE BRACKETS
MAX 30"
SERRER
LES SUPPORTS
(762 MM)
DRILL THROUGH
LOWER WALL ON
POINT "A"
A
PERCER LA PARTIE
INFÉRIEURE DU
MUR AU POINT DE
A
PERÇAGE "A"
B
9C
9D
9E
B
B
B
PUSH
TO
ADJUST
TIGHTEN
HEIGHT
THE SCREWS
SERRER
LES VIS
POUSSER
POUR
AJUSTER
LA HAUTEUR
A
A
A
A
9
No
Description
Valve - Trim for
Valve - Garniture
9B
Pressure Balanced
pour valve à pression
A
Valve with Volume
équilibrée avec
Control
contrôle de volume
B
A-1
Handle kit
Ensemble de poignée
A-2
Index
Index
A-3
Allen screw
Vis Allen
A-4
Trim cap
Garniture d'écrou
A-5
Ceramic cartridge
Cartouche céramique
Plate screws
Vis de la plaque de
A-6
(pkg of 2)
finition (pqt de 2)
Face plate with
Plaque de finition avec
A-7
seal joint
joint d'étanchéité
Screw cover plate
Cache-vis avec
A-8
with o-ring
joint torique
Sliding bar with hand
Ensemble de douche
A
shower kit, water
à main sur glissière,
B
supply elbow and
coude d'alimentation
flexible hose
et boyau
B-1
Flexible hose
Boyau
30" sliding bar kit
Ensemble de barre
B-2
(includes flexible hose
à glissière 30 po
9F
96179)
(incluant boyau 96179)
B-3
Hand shower
Douche à main
B
B-4
Water supply elbow
Coude d'alimentation
Support pour douche
B-5
Hand shower holder
à main
B-6
Wall support
Support murale
C
Spout
Bec de bain
A
C
Part/Pièce
AXO99VTCP
FCKTS2015
B4
C94001CAP
923001
FCDEC7012
FC9AC010
C94680-7A
FCDEC7049
B3
FCDEC7027
B90-831
B1
96179
B90-830
FCSPS2037
B92-003
B93-800
B93-801
FCSPS9009
A6
A8
A5
A4
A1
A3
A2
Axo
COLLECTION
B6
KIT: SHOWER FAUCET - TRIM
ROBINET POUR DOUCHE - GARNITURE
B2
B5
B6
CARE INSTRUCTIONS
Rinse the product with clear water.
Dry the product with a so cloth.
DO NOT:
Use abrasive cleansers, cloths,
or paper towels. Use any cleaning
agents containing acid, polish, wax,
alcohol, ammonia, bleach, solvent
or any other corrosive or harsh
chemical cleansers.
Customer Service
Monday to Friday:
8 a.m. - 4:30 p.m. E.S.T.
1-800-361-5960
Tel:
Replacement parts are available on order
A7
Pièces de remplacement disponibles sur commande
AXO125CP
1.5
GPM
5.7
l/min
INSTRUCTIONS D'ENTRETIEN
Rincer le robinet avec de l'eau claire
et l'essuyer avec un tissu doux.
À NE PAS FAIRE :
Utiliser des tissus ou essuie-tout
abrasifs, produits ne oyants
contenant de l'acide, agent polisseur,
cires, alcool, ammoniaque, eau de
Javel, solvants ou tout autres
produits chimiques corrosifs.
Service à la clientèle
Lundi au vendredi :
8 h 00 à 16 h 30 H.N.E.
1-888-533-8313
Fax :
info@belangerfaucets.com
For warranty and to register your product
Garantie et enregistrement de votre produit
belangerfaucets.com
