Do not try to repair the car seat by yourselves. this may led to resulting damage, if it is not done by a
professional.
IMPORTANT! The diagrams and figures in this instruction are illustrative and indicative only.
MAIN PARTS OF THE CAR SEAT: A. Headrest; B.Upholstery of the seat; C.
Headrest adjustment lever;
INSTALLING THE ISOFIX SYSTEM – APPLICABLE FOR FIGURE SECTION C and D
Step 1: Install the guides of ISOFIX attachments to the vehicle's ISOFIX anchorage points, which are located between
the surface and the backrest of the vehicle seat.
Step 2: Press ISOFIX button to release ISOFIX attachments and pull them out (position "longest attachments").
Step 3: Place the child seat on the car seat and direct the two ISOFIX connectors to the ISOFIX anchorage points on the
car seat.
Step 4: Press one of the ISOFIX connectors to engage it to the ISOFIX anchorage point with a 'click'. Repeat on the
other side to secure both ISOFIX connectors. The ISOFIX indicator should be green on both sides. Installation is
completed. WARNING! The ISOFIX connectors are only fitted correctly if both ISOFIX system indicators are marked
green.
Step 5: Press the car seat firmly against the backrest of the vehicle seat. Shake the child seat to make sure it is securely
fastened and check the green safety buttons again.
Press the ISOFIX button again to release the lugs from the guides.
The upper anchor point is fixed device on the trunk or the floor of the vehicle.
Press the adjustment button on the top tether to adjust its length. Slide the straps of the top tether through the upper
guide hooks. Pull the upper part of the top tether and press the adjuster to secure the strap to the back of the car seat.
The attachment points of the device are in 3 positions (A/B/C).
top tether adjuster show „green color". If the indicator does not show green, reinstall.
ATTENTION! After installation make sure the car seat is firmly and securely secured (4).
HEAD SUPPORT ADJUSTMENT – APPLICABLE FOR FIGURE SECTION C, D and E
To adjust the head support, pull and hold the head support release handle. Pull the handle up to move the head
support to a higher position. Hold the handle and push the head support down to move it to a lower position. When
the head support is in the desired position, release the handle to lock it. If the child seat is used forward-facing, the
head restraint must be adjusted so that the straps of the 5-point harness are at the same height or slightly above the
child's shoulder.
PUTTING A 5-POINT SAFETY HARNESS- APPLICABLE FOR FIGURE SECTION C
Step 1: Hold down the harness adjustment button and pull the shoulder belt towards you as far as possible. Make sure
to pull the shoulder belt under the chest pads as shown in Figure 1.
Step 2: Press the red button on the 5-point belt buckle to unbuckle it.
Step 3: Put the child to sit in the seat. Slide the shoulder belts over the child's shoulders and tuck the tongues of the
buckle into each other. Lock the tucked tongues into the buckle.
Step 4: Pull both shoulder belts to tighten the lap belt. Make sure the lap belt is positioned low down so that the child's
pelvis firmly gripped.
Step 5: Pull up on the 5-point belt adjuster until the belt secures the child properly. Pull the two chest pads to the
lowest position.
REMOVING THE 5-POINT SAFETY HARNESS - APPLICABLE FOR FIGURE SECTION D and E
REMOVING THE 5-POINT SAFETY HARNESS
ATTENTION! The 5-point safety harness of car seat must be removed when child reaches height 100-150 cm.
Step 1: Unlock the belt from central buckle, remove the crotch pad and insert the buckle through the slot of fabric
cover.
MAIN PARTS OF THE CAR SEAT - A
ISOFIX connectors; G. Isofix connector extraction and release buttons.
F.
INSTALLING THE TOP TETHER – APPLICABLE FOR FIGURE SECTION C
- FIGURE B.3
- FIGURE B.1
- FIGURE B.3
- FIGURE B.1
Tighten the belt of the top tether, until the indicator of
- FIGURE B.3
- FIGURE B.1
Shoulder belt guides; D. Lap belt guides; E.
