Annexe
•
Prev/Next
Data format: F0H 31H 2FH 6CH vvH F7H
F0H : Exclusive status
31H : Viscount ID
2FH : system control
6CH : cancel/set/comb.seq.
vvH : execute prev/next
01H=prev
02H=next
F7H: End of Exclusive
•
Couplers (Cantorum Trio Plus)
Data format: F0H 31H 2FH 70H vvH F7H
F0H: Exclusive status
31H: Viscount ID
2FH: system control
70H: coupler
vvH: type and switch
00H=III/P on
10H=III/P off
01H=II/P on
11H=II/P off
02H=I/P on
12H=I/P off
03H=III/II on
13H=III/II off
04H=I/II on
14H=I/II off
05H=III/I on
15H=III/I off
F7H: End of Exclusive
-
This message is received only.
•
Couplers (Cantorum Duo Plus)
Data format: F0H 31H 2FH 70H vvH F7H
F0H: Exclusive status
31H: Viscount ID
2FH: system control
70H: coupler
vvH: type and switch
00H=II/P on
10H=II/P off
01H=I/P on
11H=I/P off
03H=II/I on
13H=II/I off
F7H: End of Exclusive
-
This message is received only.
•
Orchestra volume
Parameter: ORC
Video page: Levels
Data format: F0H 31H 2FH 72H vvH F7H
F0H: Exclusive status
31H: Viscount ID
2FH: system control
72H: orchestra volume
vvH: orchestra volume value (00H–7FH, 0-127)
F7H: End of Exclusive
•
Orchestral Voice Change
Data format: F0H 31H 2nH 41H xxH yyH iiH ttH
v1H v2H b1H b2H o1H o2H u1H u2H kkH F7H
F0H: Exclusive status
31H: Viscount ID
Reference Manual
2nH: channel number (n=0H–EH, 0-15)
41H: orchestral voice change
xxH: voice id – first byte
yyH: voice id – second byte
iiH:alternative voice id
ttH: timbre type
05H=single
06H=layer
07H=split
v1H:voice1/L volume
v2H:voice2/R volume
b1h: voice1/L brilliance
b2h: voice2/R brilliance
o1H:voice1/L octave shift
o2H:voice2/R octave shift
u1H:voice1/L sustain enable
u2H:voice2/R sustain enable
kkH: split key
F7H: End of Exclusive
-
This message is transmitted only when an
alternative orchestral voices changes after
recalling a combination.
-
With Single type, voice2 bytes are fixed to 40H
With Single and Layer types, "split key" byte is
-
not used.
-
After recalling a combination, if the orchestral
voice is setted as in the Pipe Set, the message
change to: F0H 31H 2sH 41H xxH yyH 00H 7FH
00H 00H 00H 00H 00H 00H 00H 00H 00H F7H
SYSTEM REAL TIME MESSAGES
FEH: Active Sensing
FEH is transmitted every 300 msec. whenever is no
other MIDI data being transmitted.
FR - 64
Cantorum Trio – Duo – Uno Plus
