Lux Tools D-MHA-9 Set Notice Originale page 27

– Regularly instill oil into the hose connec-
tion (4).
Storage and transport
Storage
• Store the device and any accessories in a
dry, well-ventilated place.
• In case of longer periods without opera-
tion, protect the device and its accesso-
ries against soiling and corrosion.
Transport
• Use the original packaging to ship when-
ever possible.
Fault/malfunction
Product not running.
No pressure or only low pres-
sure is built up.
If you can't fix the fault yourself, contact your
nearest vendor. Please be aware that any
improper repairs will also invalidate the war-
ranty and additional costs may be incurred.
Disposal
Disposal of the appliance
This appliance must not be disposed of with
regular household waste! Dispose of the
appliance in the appropriate manner. For
more information, consult your community
waste disposal service.
Disposal of the packaging
The packaging consists of cardboard
and correspondingly marked plastics
that can be recycled.
– Make these materials available
for recycling.
Technical data
Item number
Max. operating pressure
Permissible operating tem-
perature
Hammer rate
Cause
Device defective?
No pressure?
Lack of lubrication?
Air flow setting screw closed? Turn the setting screw (6) anti-
System contamination?
Leaks?
305597
0,63 MPa
−10 °C to
+70 °C
-1
3000 min
Troubleshooting
If something stops working...
DANGER! Risk of injury! Improper
repairs can result in the product func-
tioning unsafely. This endangers
yourself and your environment.
Malfunctions are often caused by minor
faults. You can easily remedy most of these
yourself. Please consult the following table
before contacting the vendor. You will save
yourself a lot of trouble and possibly money
too.
Remedy
Contact your local vendor.
Check pressure system, con-
nections and hoses.
Check the compressed air
maintenance unit.
clockwise as far as it will go.
Check connections, check
pressure system.
Check all connections and
hoses for tightness or clog-
ging.
Item number
Stroke
Tool mount
Connection thread
Air consumption
Sound power level (L
Sound pressure level (L
Vibration
Weight
*) The specified values are emission values and do not necessarily
represent safe workplace values. Although there is a correlation
between emission and immission levels, this cannot be used to
infer whether additional safety measures are necessary or not.
Factors which affect the current immission levels at the work-
place, include the type of room, other sources of noise, e. g. the
number of machines operating and other processes taking place
in the vicinity. Permitted workplace values can differ from coun-
try to country. This information is designed to help the user to
better assess the dangers and risks. Determination of noise
emission values in accordance with EN 60745-1.
**) The specified vibration emission value was measured in accord-
ance with a normed test procedure and can be used in order to
compare one tool with another. The specified vibration emission
value can also be used for an introductory evaluation of the
exposure. The vibration emission value may fluctuate from the
specified value during actual use of the power tool. These fluc-
tuations will depend on the way in which the power tool is used.
Try to keep vibrations to a minimum. One method of reducing
the vibration load is, for example, limiting the length of time you
GB
305597
66 mm
10,2 mm
13,2 mm (G¼")
170 l/min
)* 108,9 dB(A)
WA
(K = 3 dB(A))
)* 98 dB(A)
PA
(K = 3 dB(A))
≤25 m/s²
(K = 1,5 m/s²)
2,6 kg
27
