1.2

Display screen

Figure 1.3: left: In the 'drive' position: In the 'adjustment options' position:
Part
D1: Battery indicator
D2: Maximum speed
D3: Adjustment option
D4: Profile
D5: Speed indicator
D6: Kilometre (/ Mileage) counter
D7: Clock
Function
Displays the power level of the battery
Displays the maximum speed limit as set by the
user
Displays the selected adjustment options
Displays the selected profile
Displays a graph of the actual speed
Displays the actual speed
Displays the time
The controller
21
