Inserting and Removing the Battery Pack from the
Tool (Fig. B)
nOTE: Make sure your battery pack
To Install the Battery Pack into the Tool Handle
1. Align the battery pack 6
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap into place.
To Remove the Battery Pack from the Tool
1. Press the release button
out of the tool handle.
2. Insert battery pack into the charger.
Fuel Gauge Battery Packs (Fig. B)
Some D WALT battery packs include a fuel gauge which
e
consists of three green LED lights that indicate the level of
charge remaining in the battery pack.
To actuate the fuel gauge, press and hold the fuel gauge button.
A combination of the three green LED lights will illuminate
designating the level of charge left. When the level of charge
in the battery is below the usable limit, the fuel gauge will not
illuminate and the battery will need to be recharged.
nOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end‑user application.
Belt Hook and Magnetic Bit Holder (Fig. A)
(Optional Accessories)

WARNING: To reduce the risk of serious personal injury,
DO NOT suspend tool overhead or suspend objects from the belt
hook. ONLY hang tool's belt hook from a work belt.

WARNING: To reduce the risk of serious personal injury,
ensure the screw holding the belt hook is secure.
IMPORTanT: When attaching or replacing a belt hook or
magnetic bit holder, use only the screw that is provided. Be sure
to securely tighten the screw.
A belt hook 8 and magnetic bit holder
to either side of the tool using only the screw
accommodate left‑ or right‑handed users. If the hook or magnetic
bit holder is not desired at all, it can be removed from the tool.
To move belt hook or magnetic bit holder, remove the screw
that holds it in place then reassemble on the opposite side. Be
sure to securely tighten the screw.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicable regulations.

WARNING: To reduce the risk of serious personal injury,
turn tool off and disconnect battery pack before making
any adjustments or removing/installing attachments or
accessories. An accidental start-up can cause injury.
Proper Hand Position (Fig. D)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.

WARNING: To reduce the risk of serious personal injury,
ALWAYS hold securely in anticipation of a sudden reaction.
Proper hand position requires one hand on the main
handle .
11
6 is fully charged.
with the rails inside the tool's
5 and firmly pull the battery pack
10 can be attached
9 provided, to
Variable Speed Trigger Switch (Fig. A)
To turn the tool on, squeeze the trigger switch
the tool off, release the trigger switch. Your tool is equipped
with a brake. The chuck will stop when the trigger switch is
fully released.
The variable speed switch enables you to start the application at
a slow speed. The further you squeeze the trigger, the faster the
tool will operate. For maximum tool life, use variable speed only
for starting holes or fasteners.
nOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
be avoided.
Forward/Reverse Control Button (Fig. A)
A forward/reverse control button
the tool and also serves as a lock‑off button.
To select forward rotation, release the trigger switch and
depress the forward/reverse control button on the right side of
the tool.
To select reverse, depress the forward/reverse control button on
the left side of the tool. The centre position of the control button
locks the tool in the off position. When changing the position of
the control button, be sure the trigger is released.
nOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start up. This is normal and
does not indicate a problem.
Worklights (Fig. A)
There is a worklight
worklight will be activated when the trigger switch is depressed.
When the trigger is released, the worklight will stay illuminated
for up to 20 seconds. If the trigger switch remains depressed,
the worklights will remain on.
nOTE: The worklight is for lighting the immediate work surface
and are not intended to be used as a flashlight.
Quick-Release Chuck (Fig. A, C)

WARNING: Use only impact accessories. Non-impact
accessories may break and cause a hazardous condition. Inspect
accessory prior to use to ensure that it con tains no cracks.
nOTE: The chuck accepts 6.35 mm hex accessories and
25.4 mm bit tips only. Using 25.4 mm bits allows better access
in tight spaces.
Place the forward/reverse button
9
position or remove battery pack before changing accessories.
To install an accessory, push accessory to fully insert into
chuck . The chuck collar
4
lock accessory in place.
To remove an accessory, pull the chuck collar away from the
front of the tool. Remove the accessory and release the collar.
Usage
Your impact tool generates the following maximum torque:
Cat #
DCF787

CAUTION: Ensure fastener and/or system will withstand the
level of torque generated by the tool. Excessive torque may cause
breakage and possible personal injury.
1. Place the accessory on the fastener head. Keep the tool
pointed straight at the fastener.
2 determines the direction of
7 located above the trigger switch
in the locked off (centre)
2
does not need to be pulled up to
3
Nm Ft.-Lbs.
170 125
EnGLIsh
1 . To turn
1 . The
In.-Lbs
