Panneau arrière
W1
i
W0
q
w
q
Borne CONTROL LINK ·····································(11)
w
Borne RS-232C··················································(23)
e
Bornes audio analogiques (AUDIO) ················(14)
r
Bornes RCA PRE OUT ································(11, 22)
t
Bornes EXT. IN ·················································(18)
y
Prise CA (AC IN)················································(23)
u
Sorties CA (AC OUTLETS) ·······························(23)
Q9
Q8
Q7
Q6
W2 W3 W4
e
r
i
Bornes XLR PRE OUT·······································(11)
o
Bornes d'antenne HD Radio
(DTU ANTENNA) ··············································(20)
Q0
Bornes COMPONENT VIDEO ····················(13, 22)
Q1
Bornes audio numériques
(OPTICAL / COAXIAL / BNC) ·····················(13, 22)
Q2
Bornes HDMI·····················································(12)
Q5
Q4
Q3
Q2
Q3
Borne ETHERNET ·············································(21)
Q4
Port USB ···························································(19)
Q5
Borne XM (SAT TU) ··········································(19)
Q6
Borne WLAN ANTENNA ··································(21)
Q7
Bornes d'antennes FM/AM
(TUNER ANTENNA) ··········································(20)
Q8
Borne DENON LINK··········································(18)
Q1 Q 0
o
i
t
y
u
Q9
Prises TRIGGER OUT ·······································(23)
W0
Prises REMOTE CONTROL ······························(22)
W1
Bornes XLR audio (CD) ····································(14)
W2
Prise DOCK CONTROL ·····································(14)
W3
Borne SIGNAL GND ·········································(14)
W4
Bornes VIDEO / S-VIDEO·································(13)
