Drawing and Parts List, Recovery Shoe Assembly 4/02
3
13
13
12
12a
Page 46
CLARKE TECHNOLOGY Image 20i/ix 230V
Form #19224A
4
16
8
15
14
Ref.
Part No. Description
1
28203B
2
53619A
3
67613A
4
872010
5
36506A
6
696801
7
63063A
8
962798
9
54880A
10
81110A
11
30426A
12
54339A
12a
30042A
13
54157A
14
962333
15
49067A
16
980603
17
63061C
18
30076A
8
17
11
9
18
6
10
Shoe, Recovery
Hosebarb, Nylon
Shoe
Clamp, Hose
Manifold, Spray
Plug, ¼ Recess
Bracket, Manifold Retainer
Screw, 10-24 x ½
Housing, Spray
Nut, 10-24 Nylock S.S.
Hose, Recovery
Cap w/Gasket Asm.
Gasket, Spray
Nozzle, 110° x 1 Brass Q.D.
Screw, 10-32 x
3
/
8
Wire, Ground
Washer, #10 Ext. Lock
Bracket, Brush Adj.
Strainer
CLARKE TECHNOLOGY Operator's Manual - Image 20 230V
2
5
Qty
1
1
2
1
1
2
1
3
5
3
1
5
5
5
1
1
1
1
5
7
10
