SPECIFICATIONS
AC Operational Test Point: AC Single
Voltage Range Voltage Indicator: AC Single
DC Voltage or
Test Point: 0 - 1000V
Stored Energy
Voltage Indicator: 20 - 1000V
Range
Maximum Voltage 1000V
3
Test Point: 3 Watts @ 1000V (approx.) with fault load of any (2) corresponding test points
Maximum Power
shorted indefinitely
Consumption
Voltage Indicator: 2.1 Watts
Temperatures Operate: -20ºC to +55ºC Storage: -45ºC to +85ºC
Maximum single component failure fault current at 1000V
Failure Current Test Point: 3.2mA with a momentary short between any (2) test points
Voltage Indicator: 3.7mA with any (1) line input series power resistor shorted
Test Point: (2) 82K 3W 5% Tolerance series resistors encapsulated between each input wire
Internal
Resistance and respective test point (164KΩ 6W equivalent between any two test points)
-3.2% of applied voltage with 10M Ω input impedance voltmeter connected to any (2) test
Output Accuracy
points
Terminations (4) Wires, 8 ft, 14 AWG, 90°C @ 1000V, UL-1452, PVC Insulated w/ Nylon Jacket
Voltage Category
CAT III @ 1000V
Ratings
Housing UL Approved material, totally encapsulated including LEDs for environmental protection
Indicators: (6) Red {L1, L2, L3} and (2) Yellow {GND}, Super Bright LEDs
Note: All above ratings are LINE-TO-LINE or LINE-TO-GND
ChekVolt is a combination device used to verify the voltage presence using visual
®
indication and absence through a metered test.
or 3-Phase
1
or 3-Phase
1
any (2) wires
, (Voltages Line-to-Line or Line-to-Ground)
or 1000V
L2 L3
L1
NOTE: (4) Test point jacks accept .080" DIA. probe points.
Max, Pollution Degree 3, CAT IV @ 600 V
: 0 - 1000V @ 50/60/400Hz
3
: 20-1000V, 50/60/400 Hz
3
or 1000V
Max, pollution Degree 3
TYPICAL CONFIGURATION
THREE PHASE DELTA, 3W + GND
UL Type 4,
MEASURING EQ.
4X, 12, 13,
E311256
IP2X, IP66,
IP69
WIRE IDENTIFICATION WIRE IDENTIFICATION
Direct Current
Alternating Current
Single Phase or 3-Phase
Caution
Caution, possibility of
electrical shock
