CAUTION: All connections and couplings must be hand-tight. Do not tighten them with tools.
Otherwise damage may occur.
1. Unscrew the nut (N) from the housing (U). Remove the UV-C lamp (K) from the supplied tube (see
packaging) and carefully slide the lamp into the quartz sleeve (M). Place the lamp (K) with the contact
pins in the lamp fitting (L) and then tighten the nut (N) on the housing (U).
2. Fit the supplied pipe clamps (O). Then insert the unit into the pipe clamps. Tighten the threepiece
coupling (I) firmly, while ensuring the correct position of the sealing rings (P), both at the connections
and the quartz sleeve (see figure 2).
3. Mount the unit in the circuit by means of the three-piece coupling (I) and the glue coupling for the
flow switch (V *For amalgam only). The glue connections of the three-piece coupling are Ø63 mm
or 2". If the pipes are smaller than Ø63 mm or 2", use the Ø63 x 50 mm (T) or 2" x 1.5" x 1" adapter.
This can be glued in the three-piece coupling (I) and in the glue coupling for the flow switch (V *For
amalgam only). The inside of the adapter (T) has internal screw threads at one end, making it possible
to fit a hose tail adapter (not included) with sealing ring.
4. Insert the plug of the UV-C device into an earthed wall socket that is protected by a residual current
device.
5. Look through the transparent parts of the device to make sure the lamp is lit.
6. The device is shut off when power is disconnected from the device.
*For amalgam only
7. The glue coupling for the flow switch (V) must be positioned on the three-piece coupling (I) with
the screw thread (W) facing up (see figure 2). The glue coupling (V) can be glued to a three-piece
coupling (I). Mount the flow switch (X) which is attached to the electrical section (S) directly to the
screw thread (U) of the glue coupling (V) (see figure 2). If the flow switch is mounted differently, the
device will not work. The arrow on top of the flow switch (X) must always point in the direction of
water flow. If it points in the direction opposite the water flow, the UV-C device will remain off.
8. When no water is flowing through the device, the flow switch automatically switches the unit off.
INSTRUCTIONS FOR USE DIGITAL HOUR METER
When the UV-C device is switched on, the program will perform a self-diagnostic test. The display
shows the following indications automatically, one after the other: 8888 (display test); r and software
version number; 50H or 60H indication of the network frequency. Then the display switches to the
hour meter mode.
When the UV-C lamp is switched on for the first time, or after the reset function is used, the value
9,000 will appear on the display. A decimal point flashes beside the rightmost digit on the display
every second to indicate that the counter is running. The display is automatically set to the factory
hour meter reading of 9,000 hours. Up to 9,000 hours the UV-C lamp produces its rated radiation
level. After 9,000 hours the radiation diminishes. The radiation may then be insufficient to achieve
the desired results. If the UV-C lamp has been in use for some time and has been switched on
