Performance In Lighting TYK+ 20 Instructions D'installation page 2

234 114
20
2x (13x9) Ø11
100
203,5
1 OPTION A
DRILL
1
2 x
2x (13x9)
100
203,5
2
OPEN
5
6A
ON/OFF WIRING
N
NEUTRAL
L
LINE
L
N
5 mm
H07RN-F
15 mm
2x 1÷1,5 mm
Ø10÷14 mm
2
3107101 | ED. 02 | 03 - 2021
Max 4.5 kg
Max 0,04 m 2 Max 0,027 m
OK
2 2 x
RECOMMENDED
2 x
M8
3
PUSH
TO OPEN
6B
DALI WIRING
N
NEUTRAL
L
LINE
DA+
DALI
N L DA+ DA-
DA-
DALI
5 mm
H07RN-F
15 mm
4x 1÷1,5 mm
Ø10÷14 mm
2
Max 125°
Max 15°
OK
1 OPTION B
DRILL
1
4
1
2 x
7
2 2 x
OK
Ø13
100
203,5
5
8
RECOMMENDED
M10
INSERT
CLICK
TO CLOSE
