JessEm Micro Adjuster Guide De L'utilisateur page 11

MICRO ADJUSTER™ PARTS LIST
Item No. Part No. Part Description
1 F0363 #10-24 X ½" Pan Head Torx Screw - FOR TA FENCE
2 F0364 #10-24 X ¾" Pan Head Torx Screw - FOR MAST-R-FENCE III
3 E0311-1 Fence Mount
4 F0121 #014 O-Ring
5 E0054-33 Clamping Knob
6 M0302-3 Spindle Mount Pivot Collar
7 F0097 R-8 Bearing
8 F0302 ¼"-20 X
9 E0054-32 Adjustment Knob
10 F0502 #10-32 X
11 S0065-11 O-Ring Retaining Screw
12 F0432 #008 O-Ring
13 E0251-1 Spindle Mount Pivot Mount
14 S0076-3 T-Nut Locating Pin
15 S0014-6 Clamping T-Nut
16 S0076-2 Clamping Stud
17 S0061-20 Spindle Mount Pivot
18 S0031-14 Adjustment Nut
19 S0076-4 Spindle
20 S0054-10 Spindle Pivot Ring
21 S0079-2 Spindle Lock Pin
22 F0366 #10-24 Hex Nut - FOR TA FENCE
⁄ " Low Head Socket Screw
3
8
⁄ " Cup Point Set Screw
3
8
11
Qty
2
2
1
1
1
1
1
2
1
1
2
2
1
1
1
1
1
1
1
1
1
2
