If fitting to the 690 Duke R with the Akrapovic exhaust fitted, fit the M8 x 25mm long button
head bolt with one M8 washer through the carbon exhaust mounting bracket and into the lower
hole of the R&G exhaust hanger, before fitting the remaining M8 washer and nyloc nut to the
exposed thread as shown in picture C.

Tighten all bolts evenly.

Please ensure when the motorcycle is being used that no parts are in such a position that they may
collide/damage other bike parts (this is particularly important if using after-market cans or exhaust
systems).
Please note that it is your responsibility to ensure that no part of the exhaust
hanger or exhaust assembly fouls or comes into contact with other parts of the
machine. Do not ride the motorcycle until this aspect has been verified and you
have compressed the rear suspension (if appropriate to the design of the
motorcycle) to test this thoroughly.
