1 OVERVIEW

1A. Description
The DEL Ozone generators described in this manual are designed to
provide the benefits of ozonated water in an environmentally safe and
effective manner. The high quality, specially engineered components ensure
efficient ozone output and reliable performance.
As a result of proper use of the DEL Ozone generators, unpleasant effects of
traditional chemical use are virtually eliminated. The DEL Ozone generators
are safe and harmless to your equipment when installed properly.
1B. Specifications
Power Requirements:
Ozone 25 ..............................................................................120/240V, 0.10A, 50/60Hz
Ozone 50 ............................................................................. 120/240V, 0.24A, 50/60Hz
Ozone 100 .............................................................................120/240V, 0.31A, 50/60Hz
Location Requirements:
Mounting: Wall mount in a clean, protected area.
Ambient Temp.: 35°F - 120°F (2°C - 49°C)
2A. Location
The DEL Ozone units are designed for wall mounting. Mount generator in
a clean, protected area, either indoors or outdoors (preferably out of direct
sunlight). Locate generator out of reach of sprinklers or drainage spouts.
Allow sufficient access for maintenance, all tubing, and electrical wires.
Ozone generator should be installed at least (not less than) one foot above
the maximum water level.
