Table Des Matières - Promise Technology VessRAID 1000f Serie Guide De Démarrage Rapide

VessRAID Task List
• Task 1: Unpacking the VessRAID (page 3)
• Task 2: Installing the LCD Panel (Optional) (page 7)
• Task 3: Mounting VessRAID in a Rack (page 9)
• Task 4: Installing Disk Drives (page 12)
• Task 5: Making Data and Management Connections (page 15)
• Task 6: Setting Up Serial Cable Connections (page 29)
• Task 7: Connecting the Power (page 30)
• Task 8: Setting the IP Address (page 34)
• Task 9: Creating Logical Drives with WebPAM PROe (page 40)
• Contacting Technical Support (page 47)
Task 1: Unpacking the VessRAID
The VessRAID box contains the following items:
• VessRAID Unit
• Quick Start Guide printed
• RJ11-to-DB9 serial data cable
• Screws for disk drives
(70 pieces for 16-bay, 50 pieces
for 12- and 8-bay)
A Battery Backup Unit (BBU) is optional on the VessRAID subsystem. In the
event of a power failure, the BBU powers the controller cache to preserve any
data it contains.
This is a Class A product. In a domestic environment this product
may cause radio interference in which case the user may be
required to take adequate measures.
The electronic components within the VessRAID enclosure are
sensitive to damage from Electro-Static Discharge (ESD).
Observe appropriate precautions at all times when handling the
VessRAID or its subassemblies.
Task 1: Unpacking the VessRAID
• 1.5m (4.9 ft) Power cords
(1700 models, 1; 1800 models, 2)
• CD with SNMP files, Product
Manual and Quick Start Guide in
PDF format
Warning
Warning
