Surly Dummy Instructions page 2

Tools Needed
Grease
Parts Included
(8) M5 x 0.8 x 20mm stainless flanged button head socket cap screws (for Dummy or Big Fat Dummy Deck installation, see Deck
Instructions for proper assembly)
Installation
1. Apply a small amount of grease to the exterior surface of each rail tube where the
rail will be inserted into the long-tail vertical frame tubes.
2. Insert the front part of the rail (the end without bottle cage bosses) into the front
vertical Big Dummy frame tube. It will go into the frame 15mm before the rear
part of the rail can be inserted. Apply light downward pressure to both ends of the
rail, alternating between the front and rear, until both ends hit their dead stops
and are fully seated in the frame.
3. You are now ready to install the Dummy Bags and the Dummy Deck onto the rails.
Ongoing Maintenance
If you lack proper tools, knowledge, or patience to get the job done right, visit your friendly local bike mechanic for assistance.
Spare parts are available in the event that you break or lose something.
Your new Dummy Rails require little maintenance. Periodically check the tightness of the hardware. Spray a little oil inside the
tubes on occasion if you're prone to riding in wet conditions.
WARNING: Improper installation of bolts may lead to product failure, causing serious injury. Do not exceed specified
torque values. Periodically inspect bolts and retighten if required.
Frequently check to make sure that all of the rack hardware is properly torqued per these instructions. Check to make sure that
the rack mounting bolts are properly tightened and secure the rack to the bicycle frame. Periodically check for any signs of cracking
or failure and discontinue use if rack is damaged.
Limited Warranty
This Surly product is warranted against defects in materials and workmanship for one year from the date of retail purchase of the
product, subject to the limitations detailed below. Save your dated receipt for proof of purchase.
This warranty does NOT cover the following:
• Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assembler
• Products that have been modified, neglected, used in competition or for commercial purposes, misused or abused, involved in
accidents or anything other than normal use
• Installation of components, parts or accessories not originally intended for or compatible with Surly product as sold
• Damage or deterioration to the paint, surface finish, aesthetics or appearance of the product
• Normal wear and tear
• Labor required to remove and/or refit and re-adjust the product within the bicycle assembly
This limited warranty is expressly limited to the repair or replacement of a defective product, at the option of Surly, and is the sole
remedy of the warranty. This limited warranty applies only to the original purchaser of the Surly product and is not transferable.
This warranty applies only to products purchased through an authorized dealer or distributor. In no event shall Surly be liable for
any loss, inconvenience or damage, whether direct, incidental, consequential, or otherwise resulting from breach of any express or
implied warranty or condition, of merchantability, fitness for a particular purpose, or otherwise with respect to our products except
as set forth herein.
This limited warranty gives the consumer specific legal rights, and those rights and other rights may vary from place to place.
This limited warranty does not affect your statutory rights.
Warranty Process
We will happily back up our products if there is a problem that is our fault. If you and your shop think your Surly product is worthy
of a warranty inspection, please return the product to the original place of purchase, accompanied by a sales receipt.
TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR
IMPLIED WARRANTIES OR CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE.
6400 West 105th Street, Bloomington, MN 55438
P 877.743.3191 E derby@surlybikes.com W surlybikes.com
212301 12/19 | 85-000411_INST_F
