Fitting kit
- 4 BHc 6x25 screws
- 4 Ø6 L : 10mm spacers
- 2 pieces of aluminium railings
Assembly
- Remove the original radiator covers. Stick the half of the rubber seal on both edges of scoops that
will be in touch with the gas tank (see photo).
- Place the scoops on the motorbike and fit them with the provided screws and washers by inserting
the spacers between the radiator and scoops.
- Aluminium railings may be fitted in option at the air intakes level with silicone.
* Painted and varnished parts are not guaranteed against high pressure steam washes or aggressive cleaning products which can damage them and unstuck the varnish. We advise moreover, according to the technical data
of our painting suppliers, to wait one month to obtain a complete polymerization of varnish.
* Accessories gone up on the motorbike will not be any more considered as new and will be neither retaken nor exchanged.
* Ermax accessories are foreseen for original equipments. They will not be guaranteed if they are used in others conditions.
* Due to vehicules made tolerances, beyond our control, some Ermax products might need adjustings to fit.
* Aluminium screws are garanted until 6 Nm by our suppliers. Care to excessive clampings which may damage or break screws.
- 4 Ø6 washers
- 40 cm of rubber seal
« ATTENTION »
FITTING INSTRUCTIONS
« SCOOPS »
GSR 600 2006 → ∞
Rubber seal location
