Night mode: The detector generates an alarm signal or message when
activated by a person walking in front of it.
Remote test: The control panel monitors the detector's sensor and
associated on-board signal processing circuitry.
Self test: The detector itself monitors the sensor and associated on-board
signal processing circuitry.
Technical fault (TF): The fault signal or message that is generated on the
AM relay when the detector suffers a fault.
Walk test: An operational test done by the installer to see if the equipment
will generate an alarm.

11. Technical specifications

Input power
Peak-to-peak ripple
Current consumption:
Normal operation
Alarm
Maximum
Control input voltage
(terminals 10-11-12)
Mounting height
Target speed range
Alarm relay
Alarm output
Tamper output
Trouble output
Alarm time
Detector start-up time
Operating temperature
Relative humidity
Dimensions (H x W x D)
Weight
Number of curtains
Viewing angle
IP/IK rating
9 VDC to15 VDC (12 Vnominal)
Optical relay is immune to magnetic influence
(11 at 65.6 ft. and 1 at 197 ft.)
- 19 -
2 V (at 12 VDC)
Low 0 to1.5 VDC
High 3.5 to 15 VDC
Min 1.8 m, max 3.0 m
(Min 5.90 ft., max 9.84 ft.)
10 cm/sec to 4 m/sec
(4 in./sec to 13 ft./sec)
80 mA at 30 VDC max.
80 mA at 30 VDC max.
80 mA at 30 VDC max.
-10°C to +55°C
(14°F to 130°F)
175 x 93 x 66 mm
(6.88 x 3.66 x 2.60 in.)
275 g (9.70 oz.)
11 at 20 m and 1 at 60 m
86° at 20 m and 3° at 60 m
20 mA
24 mA
34 mA
3 sec
70 sec
Max. 95%
IP30 IK02
