Accessories - Delta Light FRAGMA 4X4 94014 ADM DIM1P Mode D'emploi

A
B
87
Ø187
262
220
C
D
A
Ref: 23610 XXXX
23613 0010 FRAGMA 4X4 BEAM LENS 26°
23613 0040 FRAGMA 4X4 BEAM LENS 47°
23613 0070 FRAGMA 4X4 SOFTENING LENS (only with 14°)
23613 0100 FRAGMA 4X4 LINEAR SPREAD LENS (only with 14°)
23613 0160 FRAGMA 4X4 WALLWASH LENS (only with 14°)
23613 0190 FRAGMA 4X4 FLAPS
23613 0220 FRAGMA 4X4 HONEYCOMB
23613 0250 FRAGMA 4X4 RASTER
B
FLAT SIDE
ROUGH SIDE
Installation Instruction
removal of lens
A
A
Place the suction cup in
one of the four corners.
3

ACCESSORIES

B
A
C
