SETUP AND USE

BREATHING TUBE
FIGURE 2.1
Insert the threaded end of the breathing tube
(04-835) into the threaded hole in the back
of the Z-LINK and screw the breathing tube
®
in completely without over tightening.
FOR USE WITH RPB
When the Z-LINK Respirator is being used in conjunction with the RPB
®
please refer to the RPB
Note: The RPB
PX4 is a Powered Air Purifying Respirator, therefore care must be taken
®
when selecting the correct filter for the application the respirator will be used in.
10
PX4 AIR - SEE THE PAPR USER MANUAL
®
PX4 PAPR User Instruction Manual for set up and use of the assembly.
®
For PAPR, insert the bayonet end of the
breathing tube into the outlet of the PX4 AIR
PAPR and twist it in until it is secure.
For Supplied Air, screw on the breathing to
the flow control device.
®
FIGURE 2.3
PX4 AIR PAPR,
