Pubert Devor X 40 Notice D'utilisation page 21

2
8
5
11
10
15
13
6
1
3
4
12
9
5 - EN
7
1 - Transportation handle
2 - blade casing
3 - Obstruction clearance hatch
4 - Locking lever for obstruction
clearance hatch
5 - Transportation wheel
6 - Feeding chute
7 - Flap
8 - Deflector
9 - air filter casing
10 - Spark plug
11 - Exhaust silencer
12 - Petro tank cap
13 - automatic return starter
cord
14 - Throttle
15 - Oil gauge
